| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 19001-0007 |
| Color: | Blue |
| Series: | 19001 - Avikrimp |
| Connector Type: | Avikrimp, Quick Disconnect |
| Gender: | Male |
| Contact Material: | Brass |
| Voltage: | 300 V |
| Material: | Brass |
| Insulation Material: | Nylon (PA) |
| Compatible Tab Width: | 6.35mm |
| Compatible Tab Thickness: | 0.81mm |
| Orientation: | Straight |
| Insulation Type: | Full |
| Packaging: | Adhesive Tape on Reel |
| Operating Temperature Range: | -65 - 105 °C |
| Contact Mating Area Plating: | Zinc Chromate |
| Contact Mating Area Plating Thickness: | 5.08 µm |
| Contact Termination Plating Thickness: | 5.08 µm |
| Polarized to Mate: | No |
| Wire Size: | 14 AWG, 16 AWG, 1.3 - 2 mm² |
| CSA Agency Certification: | LR18689 |
| TUV Agency Certification: | R9071070 |
| UL Agency Certification: | E79133 |
| Contact Termination Plating: | Zinc Chromate |
| Wire Insulation Diameter: | 4.32 mm |
| Glow Wire Capable: | No |
| Lock to Mating Part: | No |
| Material Flammability Standard: | 94V-2 |
| Part Aliases: | 0190010007 BB-5262T |
| SKU: | MOL19001-0007 |
19001-0007
| Heilind Number: | MOL19001-0007 |
| Manufacturer: | Molex |
| Manufacturer Number: | 19001-0007 |
| Datasheet: | Product Specification |
| ECAD Model: | |
Description:
Avikrimp Quick Disconnect, Male, for 14-16 (2.00-1.30mm?), Mylar Tape, Tab 6.35 x 0.81mm
More >>Specifications
Detailed Description
The 19001-0007 is a high-quality Avikrimp Quick Disconnect designed for efficient and reliable electrical connections. This male connector is compatible with 14-16 gauge wires, featuring a 6.35 x 0.81mm tab for easy installation. Constructed from durable brass with a nylon insulation, it offers excellent conductivity and protection. With a voltage rating of 300V and operating temperature range of -65 to 105°C, this connector is suitable for a wide range of applications. It is CSA, TUV, and UL certified, ensuring safety and quality. The zinc chromate plating on the contact area and termination provides added corrosion resistance. RoHS compliant and available for immediate shipping, the 19001-0007 is the perfect choice for your crimp terminal needs.
