173109-0081
FCT Standard-Density D-Sub Connector, Male, Straight, Solder Cup, Gold Plating, 200 Mating Cycles, 37 Circuits
Part Aliases: Molex 1731090081 Molex F37P0G2
The FCT Standard-Density D-Sub Connector, a high-performance solution for your connectivity needs. This male connector features a straight orientation and solder cup termination method, with gold plating for enhanced durability. With 37 circuits and a current rating of 7.5 A, it ensures reliable power and signal transmission. Designed for longevity, it offers 200 mating cycles and is constructed from PBT and steel for robustness. Its tin shell plating and IP20 rating provide protection against environmental factors. Whether for industrial or commercial applications, this connector is a dependable choice. With its RoHS non-compliance, it also meets environmental standards. Upgrade your connectivity setup with the FCT Standard-Density D-Sub Connector.
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 173109-0081 |
| Color: | White |
| Series: | 173109 |
| Amperage: | 7.5 A |
| Gender: | Male |
| Number of Contacts: | 37 |
| Number of Rows: | 2 |
| Termination Method: | Solder Cup |
| Contact Material: | Copper Alloy |
| Contact Plating: | Gold Over Nickel |
| Pitch: | 2.84 mm |
| IP Rating: | IP20 |
| Shell Plating: | Tin |
| Number of Ports: | 1 |
| Orientation: | Straight |
| Insert Material: | PBT |
| Shell Material: | Steel |
| Operating Temperature Range: | -55 - 125 °C |
| Number of Contacts Loaded: | 37 |
| Mating Cycles: | 200 |
| Panel Mount: | Rear |
| Panel Mount Method: | Flange |
| PCB Locator: | No |
| Shielded: | Yes |
| PCB Retention: | Without |
| Type: | Standard Density |
| Mating Pitch: | 2.84 mm |
| Polarized to Mate: | Yes |
| Wire Size: | 20 AWG |
| Waterproof Dustproof: | No |
| Product Name: | FCT Products |
| Part Aliases: | 1731090081 F37P0G2 |
| SKU: | MOL173109-0081 |
Environmental Initiative Details
| Environmental Initiative: | RoHS |
|---|---|
| Compliant: | Unknown |
| Date of this Information: | Unknown |
| Notes: |
