| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 172765-5121 |
| Series: | 172765 - Mini-Fit TPA2 |
| Amperage: | 11.5 A |
| Connector Type: | Mini-Fit TPA2 |
| Gender: | Male |
| Termination Method: | Crimp or Compression |
| Contact Material: | Brass |
| Contact Plating: | Tin |
| Voltage: | 600 V AC/DC |
| Circuit Application: | Power |
| Contact Mating Area Plating: | Tin |
| Contact Mating Area Plating Thickness: | 2.5 µm |
| Mating Cycles: | 30 |
| Contact Termination Plating Thickness: | 2.5 µm |
| Wire Size: | 22 AWG, 24 AWG |
| Connector System: | Wire to Wire |
| Contact Termination Plating: | Tin |
| Wire Insulation Diameter: | 1.07 - 1.65 mm |
| Part Aliases: | 1727655121 |
| SKU: | MOL172765-5121 |
172765-5121
Specifications
Detailed Description
The Mini-Fit TPA2 Male Crimp Terminal, SKU 172765-5121, is a reliable and high-performance connector designed for power applications. Constructed from brass with pre-plated tin for enhanced durability, this terminal accommodates 22-24 AWG wires with an insulation diameter of 1.07-1.65mm. It is suitable for wire-to-wire connections and features a tin-plated contact termination for efficient conductivity. With a current rating of 11.5A and a voltage tolerance of 600V AC/DC, this connector ensures reliable power transmission. It is RoHS compliant and part of the Fit Family Power Connectors, Mini-Fit Connector System, making it a versatile and dependable choice for various industries.
