| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 172287-1102 |
| Color: | Black |
| Series: | 172287 |
| Amperage: | 14 A |
| Connector Type: | Ultra-Fit |
| Number of Contacts: | 2 |
| Number of Rows: | 1 |
| Termination Method: | Through Hole |
| Contact Material: | Copper Alloy |
| Body Orientation: | Straight |
| Pitch: | 3.5 mm |
| Voltage: | 400 V AC/DC |
| Material: | Liquid Crystal Polymer |
| Orientation: | Vertical |
| Keying: | Yes |
| Tail Length: | 3.2 mm |
| Operating Temperature Range: | -40 - 120 °C |
| Contact Mating Area Plating: | Tin |
| Contact Mating Area Plating Thickness: | 1.524 µm |
| Number of Contacts Loaded: | 2 |
| Mating Cycles: | 25 |
| PCB Locator: | Yes |
| PCB Retention: | Yes |
| Polarized to PCB: | Yes |
| Contact Termination Plating Thickness: | 1.524 µm |
| Polarized to Mate: | Yes |
| PCB Thickness (Recommended): | 1.6 mm |
| Connector System: | Wire to Board |
| Contact Termination Plating: | Tin |
| Maximum Solder Process Temperature: | 260 °C |
| Lead Free Process Capability: | WAVE |
| Duration at Max. Process Temperature (seconds): | 090 |
| Max. Cycles at Max. Process Temperature: | 002 |
| Termination Pitch: | 3.5 mm |
| Glow Wire Capable: | Yes |
| Guide to Mating Part: | No |
| Lock to Mating Part: | Yes |
| Surface Mount Compatible: | Yes |
| Breakaway: | No |
| Make First / Break Last: | No |
| Shroud Type: | Fully |
| Product Name: | Ultra-Fit |
| Material Flammability Standard: | 94V-0 |
| Part Aliases: | 1722871102 |
| SKU: | MOL172287-1102 |
172287-1102
Specifications
Detailed Description
Introducing the Ultra-Fit Vertical Header, a high-performance PCB connector designed for power applications. With a compact 3.50mm pitch and featuring a single row with 2 circuits, this header is perfect for space-constrained designs. The inclusion of solder clips ensures secure and reliable connections, while the tin plating and glow wire capability guarantee enhanced safety and durability. Constructed from black liquid crystal polymer, it offers excellent thermal and mechanical properties, with an operating temperature range of -40 to 120 °C. Fully shrouded and featuring polarized mating, this connector ensures proper alignment and mating integrity. RoHS compliant and lead-free process capable, the Ultra-Fit Header is ideal for a wide range of applications in various industries.
Frequently Bought Together
| Product | Part # | Description | Stock |
|---|---|---|---|
 | Molex 172704-0083 | FCT Plastic Dust Cap for Size 1 Male D-sub, Red |  |
