| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 171971-0005 |
| Color: | Black |
| Series: | 171971 |
| Amperage: | 3 A |
| Connector Type: | SL |
| Number of Contacts: | 5 |
| Number of Rows: | 1 |
| Termination Method: | Through Hole |
| Contact Material: | Brass |
| Pitch: | 2.54 mm |
| Voltage: | 250 V |
| Material: | Liquid Crystal Polymer |
| Orientation: | Vertical |
| Keying: | No |
| Tail Length: | 3.3 mm |
| Operating Temperature Range: | -40 - 105 °C |
| Contact Mating Area Plating: | Matte Tin |
| Contact Mating Area Plating Thickness: | 2.54 µm |
| Number of Contacts Loaded: | 5 |
| PCB Locator: | No |
| PCB Retention: | Without |
| Polarized to PCB: | Yes |
| Contact Termination Plating Thickness: | 2.540 µm |
| Polarized to Mate: | Yes |
| PCB Thickness (Recommended): | 1.57 mm |
| Connector System: | Wire to Board |
| Contact Termination Plating: | Matte Tin |
| Termination Pitch: | 2.54 mm |
| Glow Wire Capable: | No |
| Guide to Mating Part: | No |
| Lock to Mating Part: | Yes |
| Breakaway: | No |
| Make First / Break Last: | No |
| Shroud Type: | Fully |
| Product Name: | SL |
| Part Aliases: | 1719710005 |
| SKU: | MOL171971-0005 |
171971-0005
| Heilind Number: | MOL171971-0005 |
| Manufacturer: | Molex |
| Manufacturer Number: | 171971-0005 |
| Datasheet: | RoHS Certificate of Compliance |
| ECAD Model: | |
Specifications
Detailed Description
Introducing the SL LCP VERT HDR ASSY TH MATTIN SL LCP VERT HD ASSY, a high-performance PCB pin header connector designed for reliable power and signal transmission in electronic applications. With a sleek black housing and featuring 5 contacts arranged in a single row, this connector ensures efficient connectivity. Constructed with durable liquid crystal polymer material and brass contacts plated with matte tin, it guarantees longevity and stable performance even in harsh environments. Its through-hole termination method and vertical orientation make it easy to install on PCBs, while its low profile design saves space. Rated for 3A and 250V, with a wide operating temperature range from -40 to 105°C, this connector is suitable for various industrial and commercial settings. RoHS compliant and lead-free, it meets stringent environmental standards. Perfect for wire-to-board connections, the SL LCP VERT HDR ASSY TH MATTIN SL LCP VERT HD ASSY is a reliable and versatile solution for your connectivity needs.
