151049-2201
CP-6.5 Receptacle Housing, 6.50mm Pitch, Dual Row, Polarized, Positive Lock, 2 Circuits, Blue
Part Aliases: Molex 1510492201
The 151049-2201, a high-performance CP-6.5 Receptacle Housing designed for seamless wire-to-board and wire-to-wire connectivity. With a pitch of 6.50mm and featuring dual rows, this housing ensures a secure and stable connection. Boasting a polarized and positively locked design, it guarantees accurate mating every time. The blue housing, constructed from PBTP material, is not only durable but also visually distinct. With 2 circuits and a current rating of 10 A, it is suitable for a wide range of applications. Operating efficiently in temperatures ranging from -40 to 105 °C, this connector is reliable even in harsh environments. Fully RoHS compliant, it meets the highest standards of environmental responsibility. Upgrade your connectivity solutions with the 151049-2201 CP-6.5 Receptacle Housing.
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 151049-2201 |
| Color: | Blue |
| Series: | 151049 |
| Amperage: | 10 A |
| Connector Type: | CP-6.5 |
| Gender: | Receptacle |
| Number of Contacts: | 2 |
| Number of Rows: | 2 |
| Pitch: | 6.5 mm |
| Material: | PBTP |
| Keying: | Yes |
| Operating Temperature Range: | -40 - 105 °C |
| Polarized to Mate: | Yes |
| Connector System: | Wire to Board |
| Termination Pitch: | 6.5 mm |
| Glow Wire Capable: | No |
| Lock to Mating Part: | Yes |
| Product Name: | CP-6.5 |
| Material Flammability Standard: | 94V-0 |
| Part Aliases: | 1510492201 |
| SKU: | MOL151049-2201 |
Environmental Initiative Details
| Environmental Initiative: | RoHS |
|---|---|
| Compliant: | Unknown |
| Date of this Information: | Unknown |
| Notes: |
