| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 10-84-4090 |
| Color: | Natural |
| Series: | 42002 - MLX |
| Amperage: | 13.5 A, 20 A |
| Connector Type: | MLX |
| Number of Contacts: | 9 |
| Number of Rows: | 3 |
| Termination Method: | Through Hole |
| Contact Material: | Phosphor Bronze |
| Body Orientation: | Straight |
| Pitch: | 6.35 mm |
| Material: | Nylon |
| Orientation: | Vertical |
| Keying: | Yes |
| Tail Length: | 4.27 mm |
| Operating Temperature Range: | -55 - 105 °C |
| Contact Mating Area Plating: | Tin |
| Number of Contacts Loaded: | 9 |
| Mating Cycles: | 50 |
| PCB Retention: | Yes |
| Polarized to PCB: | Yes |
| PCB Thickness (Recommended): | 1.57 mm |
| Connector System: | Wire to Board |
| Maximum Solder Process Temperature: | 260 °C |
| Lead Free Process Capability: | WAVE |
| Duration at Max. Process Temperature (seconds): | 010 |
| Glow Wire Capable: | No |
| Guide to Mating Part: | Yes |
| Lock to Mating Part: | Yes |
| Surface Mount Compatible: | No |
| Breakaway: | No |
| Make First / Break Last: | No |
| Shroud Type: | Fully |
| Material Flammability Standard: | 94V-2 |
| Part Aliases: | 0010844090 A-42002-9A1A1 |
| SKU: | MOL10-84-4090 |
10-84-4090
| Heilind Number: | MOL10-84-4090 |
| Manufacturer: | Molex |
| Manufacturer Number: | 10-84-4090 |
| Datasheet: | Packaging Specifications |
| ECAD Model: | |
Description:
6.35mm Pitch MLX Power Connector Header, Vertical, 9 Circuits, PA Polyamide Nylon 6/6 94V-2, Tin (Sn) Plating, White
More >>Specifications
Detailed Description
Introducing the 10-84-4090, a high-performance 20 A (13.5 A) PCB pin header connector from the MLX series 42002. With 9 contacts arranged in 3 rows, this connector ensures reliable power and signal transmission in your electronic assemblies. Featuring a durable nylon body and straight orientation, it offers easy vertical PCB mounting with a 6.35 mm pitch. Constructed with phosphor bronze contacts and tin plating, it guarantees excellent conductivity and corrosion resistance. With a wide operating temperature range of -55 to 105 °C and RoHS compliance, it is suitable for various industrial applications. Trust the 10-84-4090 for secure wire-to-board connections in your designs.
