10-84-4120
6.35mm Pitch MLX Power Connector Header, Vertical, 12 Circuits, PA Polyamide Nylon 6/6 94V-2, Tin (Sn) Plating, White
Part Aliases: Molex 0010844120 Molex A-42002-12A1A1
The 10-84-4120, a high-performance 20A/13.5A MLX connector designed for reliable power and signal transmission in demanding applications. With 12 contacts arranged in 3 rows, this connector offers robust connectivity on a 6.35mm pitch. Constructed of durable nylon with phosphor bronze contacts, it ensures long-lasting performance even in harsh environments. Featuring a straight body orientation and vertical termination, it provides easy integration onto PCBs. With keying for added security and UL and CSA agency certifications, this connector guarantees safety and compliance. RoHS compliant and lead-free solder capable, it is environmentally friendly. Whether for industrial machinery or telecommunications systems, the 10-84-4120 is the ideal choice for high-reliability wire-to-board connections.
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 10-84-4120 |
| Color: | Natural |
| Series: | 42002 - MLX |
| Amperage: | 13.5 A, 20 A |
| Connector Type: | MLX |
| Number of Contacts: | 12 |
| Number of Rows: | 3 |
| Termination Method: | Through Hole |
| Contact Material: | Phosphor Bronze |
| Body Orientation: | Straight |
| Pitch: | 6.35 mm |
| Material: | Nylon |
| Orientation: | Vertical |
| Keying: | Yes |
| Tail Length: | 4.27 mm |
| Packaging: | Bag |
| Operating Temperature Range: | -55 - 105 °C |
| Contact Mating Area Plating: | Tin |
| Number of Contacts Loaded: | 12 |
| Mating Cycles: | 50 |
| PCB Retention: | Yes |
| Polarized to PCB: | Yes |
| PCB Thickness (Recommended): | 1.57 mm |
| Connector System: | Wire to Board |
| CSA Agency Certification: | LR19980 |
| UL Agency Certification: | E29179 |
| Maximum Solder Process Temperature: | 260 °C |
| Lead Free Process Capability: | WAVE |
| Duration at Max. Process Temperature (seconds): | 010 |
| Glow Wire Capable: | No |
| Guide to Mating Part: | Yes |
| Lock to Mating Part: | Yes |
| Surface Mount Compatible: | No |
| Breakaway: | No |
| Make First / Break Last: | No |
| Shroud Type: | Fully |
| Material Flammability Standard: | 94V-2 |
| Part Aliases: | 0010844120 A-42002-12A1A1 |
| SKU: | MOL10-84-4120 |
Environmental Initiative Details
| Environmental Initiative: | RoHS |
|---|---|
| Compliant: | Unknown |
| Date of this Information: | Unknown |
| Notes: |
