| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 09-50-3091 |
| Color: | Natural |
| Series: | 2139 - KK 396 |
| Connector Type: | KK 396 |
| Gender: | Receptacle |
| Housing Material: | Nylon |
| Number of Contacts: | 9 |
| Number of Rows: | 1 |
| Pitch: | 3.96 mm |
| Material: | Nylon |
| Packaging: | Bag |
| Circuit Application: | Power |
| Connector System: | Wire to Board |
| CSA Agency Certification: | LR19980 |
| UL Agency Certification: | E29179 |
| Glow Wire Capable: | No |
| Lock to Mating Part: | Yes |
| Material Flammability Standard: | 94V-2 |
| Part Aliases: | 0009503091 2139-9A |
| SKU: | MOL09-50-3091 |
09-50-3091
Specifications
Detailed Description
The 09-50-3091 is a 9-circuit KK 3.96mm Crimp Terminal Housing designed for power applications in wire-to-board connector systems. Featuring a friction ramp for secure connections, this natural-colored housing is constructed of Nylon, ensuring durability and reliability. With both CSA and UL agency certifications, it meets stringent safety standards. Each housing accommodates 9 contacts in a single row, with a pitch of 3.96mm. Designed for receptacle connectors, it includes a locking feature for added security. RoHS compliant and available for immediate shipping, the 09-50-3091 is an ideal choice for high-performance electronic systems.
