03-06-7061

MOL03-06-7061
Heilind Number:MOL03-06-7061
Manufacturer:Molex
Manufacturer Number:03-06-7061
Datasheet:RoHS Certificate of Compliance
ECAD Model:
3D Model

Description:

1.57mm Diameter Standard .062 Pin and Socket Plug Housing, 6 Circuits, without Mounting Ears, Black

More >>

Specifications

AttributeValue
Product Category:
Pin & Socket Housings & Contacts Pin & Socket Housings
Manufacturer:Molex
Manufacturer Part Number:Molex 03-06-7061
Color:Black
Series:1625
Amperage:5 A
Connector Type:Standard .062"
Gender:Plug
Number of Contacts:6
Number of Rows:3
Pitch:3.68 mm
Material:Nylon
Keying:No
Packaging:Bag
Operating Temperature Range:-40 - 105 °C
Circuit Application:Power
Polarized to Mate:Yes
Connector System:Wire to Wire
CSA Agency Certification:LR19980
UL Agency Certification:E29179
Termination Pitch:3.68 mm
Glow Wire Capable:No
Lock to Mating Part:Yes
Stackable:No
Breakaway:No
Product Name:Standard .062"
Material Flammability Standard:94V-2
Contact Detail:2x3
Part Aliases:0003067061 1625-06P1-BK
SKU:MOL03-06-7061

Detailed Description

The Standard .062" black nylon connector, part number 03-06-7061, is a versatile component designed for power applications. With a low operating temperature of -40°C and a high of 105°C, this connector is suitable for a wide range of environments. Featuring 6 contacts arranged in 3 rows, it allows for efficient wire-to-wire connections. Its UL and CSA agency certifications guarantee safety and reliability. The connector is RoHS compliant and features a polarized plug for easy mating. Durable nylon construction and a lock to the mating part ensure secure connections. Perfect for various electronic devices, this connector offers high performance and longevity.
