| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | TE Connectivity |
| Manufacturer Part Number: | TE Connectivity 41772 |
| Series: | FASTON 250 |
| Contact Material: | Brass |
| Contact Plating: | Tin |
| Overall Length: | 19.05 mm, .75 in |
| Material: | Brass |
| Compatible Tab Width: | .25 in, 6.35 mm |
| Compatible Tab Thickness: | .032 in, .81 mm |
| Terminal Type: | Receptacle |
| Orientation: | Straight |
| Operating Temperature Range: | -40 - 110 °C, -40 - 230 °F |
| Wire Size: | 18 - 22 AWG, .32 - .82 mm² |
| Crimp Type: | F-Crimp |
| Barrel Type: | Open |
| Accepts Wire Insulation Diameter: | .09 - .13 in, 2.29 - 3.3 mm |
| Product: | Quick Disconnects |
| Product Type: | Receptacle |
| SKU: | AMP41772 |
| Fully Insulated: | No |
| Connection Capacity: | Single |
| Receptacle Terminal Stock Thickness: | .41 mm / .016 in |
| UL Rating: | Listed |
| CSA Certified: | Yes |
| Mating Retention Type: | Dimple |
| Wire Insulation Support: | With |
| Line: | Premier |
| Wire/Cable Type: | Regular Wire |
| Insertion Force: | Normal |
| Sealable: | No |
| Insulated: | No |
| Terminates To: | Wire & Cable |
41772
| Heilind Number: | AMP41772 |
| Manufacturer: | TE Connectivity |
| Manufacturer Number: | 41772 |
| Datasheet: | Material Declaration (XLSX) |
| ECAD Model: | |
Specifications
Detailed Description
The FASTON 250 (6.3 MM) REC 22-18 AWG TPBR is a reliable and durable receptacle terminal designed for efficient wire connections. Constructed of high-quality brass with tin plating, it ensures excellent conductivity and corrosion resistance. With an overall length of .75 inches (19.05 mm) and a straight orientation, it offers easy installation in various applications. Suitable for wire sizes 18-22 AWG (.32-.82 mm²), it accommodates a tab width of 6.35 mm (.25 inches) and a tab thickness of .81 mm (.032 inches). Its F-Crimp design and open barrel allow for secure and efficient crimping, while its wide operating temperature range of -40 to 110°C (-40 to 230°F) ensures reliable performance in diverse environments. RoHS compliant and in stock for immediate shipping, this receptacle terminal is a dependable solution for your connectivity needs.
Frequently Bought Together
| Product | Part # | Description | Stock |
|---|---|---|---|
 | TE Connectivity 1-172169-2 | MINI UNIVERSAL M-N-L PLUG 9P |  |
 | TE Connectivity 1969507-2 | FLAG FASTON 250 HOUSING RECEPTACLE | |
 | TE Connectivity 2-322455-1 | TERMINAL,SOLIS R 12-10 10 | |
 | TE Connectivity 2-322695-2 | TERMINAL,SOLIS R HR 16-14 10 | |
 | TE Connectivity 2-33458-3 | TERMINAL,SOLIS R 12-10 1/4 | |
 | TE Connectivity 350720-1 | 09P UMNL PLUG HSG | |
 | TE Connectivity 350766-1 | 03P UMNL PLUG HSG | |
 | TE Connectivity 350777-1 | 02P UMNL PLUG HSG | |
 | TE Connectivity 350783-1 | 12P UMNL CAP HSG | |
 | TE Connectivity 4-520447-2 | ULTRA-FAST 250 ASY REC 12-10 AWG TPBR | |
 | TE Connectivity 41532 | FASTON 250(6.3MM)FLAG REC 18-12 AWG TPBR | |
 | TE Connectivity 5-747905-2 | 9 Rcpt Solder Cup, Gold Flash, | |
 | TE Connectivity 52197-1 | TERMINAL SOLIS R 6-10 | |
 | TE Connectivity 770579-1 | 08P MINI UMNL PLUG HSG | |
 | TE Connectivity 770849-9 | 09P SL156 HSG W/LCK RMP & TABS | |
Product Change Notice
| Effective Date | Description of Change | Download | |||
|---|---|---|---|---|---|
| 10/14/2024 | PCN-24-204265 - Location Change. The listed part numbers are currently sourced from TE Connectivity (TE) manufacturing site in Collegno (Italy). These part numbers will be sourced from TE Qingdao (China) manufacturing site starting on 14 October 2024 at the earliest after completion of the tool transfer. Mixed shipments may be possible until 01 April 2025. An internal release based on applicable TE specifications will be executed before any parts will be delivered, to ensure product performance is compliant with applicable TE specifications. If there is a change to the above listed schedule, we will update you further. | Download | |||
| 01/16/2023 | PCN-22-158316 - Packaging Change. Below mentioned PN will be packaged with different carton reel, according to TE Standard to optimize process and reduce shortage risk. Pls check attached documentation to show comparison between current reel and new one to be implemented. | Download | |||
| 08/10/2022 | P-22-023121 - Additional manufacturing location source. PNs listed in this notification are currently produced in TE Lickdale Plant. To optimize supply chain, manufacturing process and delivery, we are adding another source: TE Collegno Plant No tool transfer and no new tools are involved in this process. TE Collegno has got capacity. In the future there will be two manufacturing locations for listed parts: TE Lickdale and TE Collegno. | Download | |||
| 04/11/2016 | P-16-012580 - UPDATE TO PCN P-16-012528. To ensure a smooth and stable transition from SWDC to EPDC, TE will be delaying the transition from the current Santa Teresa, NM DC (SWDC) to the new El Paso, TX DC (EPDC), originally scheduled to implement February 8th - 15th, is now scheduled to implement April 11th - 15th. This delay will allow extended testing on all SAP systems and procedures to ensure a seamless transition into the new warehouse. As we migrate the product and go-live on the new SAP WM software, it is critical to ensure this testing and training is fully incorporated into the systems and operational processes in the new El Paso warehouse. Based on the revised timing of transition, both Customer Shipments and Supplier Deliveries will continue to process from the Santa Teresa, NM location: Address: 101 Lindbergh, Santa Teresa, NM 88008, DUNS Code: 036967748. See attached Customer Letter. | Download | |||
| 02/15/2016 | P-16-012528 - Location Change. TE has established a new Distribution Center in El Paso, TX to support our South-West Customers. The transition to El Paso will take place during the weekend of February 13th - 14th. | Download | |||
Availability
Immediate Shipment:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
