| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | TE Connectivity |
| Manufacturer Part Number: | TE Connectivity 350720-1 |
| Series: | Universal MATE-N-LOK |
| Housing Material: | Nylon |
| Number of Rows: | 3 |
| Mount Type: | Cable Mount (Free-Hanging) |
| Termination Method: | Crimp |
| Pitch: | .25 in, 6.35 mm |
| Voltage: | 600 V AC |
| Contact Type: | Pin |
| Row Spacing: | .25 in, 6.35 mm |
| Package Quantity: | 1 |
| Number of Positions: | 9 |
| Housing Color: | Natural |
| GPL: | 236 |
| Packaging: | Package |
| Operating Temperature Range: | -55 - 125 °C, -67 - 257 °F |
| Circuit Application: | Power & Signal |
| Sealable: | No |
| GPL Description: | Appliances |
| Connector and Contact Terminate To: | Wire & Cable |
| Product Code: | 1318 |
| Contact Layout: | Matrix |
| Connector System: | Wire to Board, Wire to Wire |
| CSA Agency Certification: | LR7189 |
| Connector Product Type: | Housing |
| ECCN: | EAR99 |
| Insertion Force: | 22.2 Newton |
| Contact Retention: | Without |
| Glow Wire Rating: | Standard Part - Not Glow Wire |
| VDE Tested: | Yes |
| Connector and Housing Type: | Plug |
| Multiple Contact Types: | Without |
| Standards Met: | UL CSA |
| Material Flammability Standard: | UL 94V-0 |
| Part Aliases: | 500-020-2570,D76178-000,403049182,AMPS-0-0350720-1 350720-1 |
| SKU: | AMP350720-1 |
350720-1
Specifications
Detailed Description
Introducing the 350720-1 Universal MATE-N-LOK Cable Mount Housing, a versatile and reliable solution for your power and signal connectivity needs. This housing, constructed of durable UL 94V-0 rated nylon, features three rows with a total of nine positions for efficient cable termination via crimping. With a wide pitch of 6.35mm (.25 in) and a high voltage rating of 600V AC, it is suitable for a variety of applications. The natural housing color and compact design make it a perfect fit for appliances and HVAC systems. VDE tested and RoHS compliant, this connector ensures safety and environmental responsibility. Upgrade your wire-to-wire or wire-to-board connections with the 350720-1 for seamless performance in any operating environment.
Frequently Bought Together
| Product | Part # | Description | Stock |
|---|---|---|---|
 | TE Connectivity 172167-1 | 4 CIR UNIV M-N-L PLUG |  |
 | TE Connectivity 172168-1 | 6 CIR UNIV M-N-L PLUG | |
 | TE Connectivity 205090-1 | HD 20 SOCKET CONTACT | |
 | TE Connectivity 205204-9 | CRIMP SNAP PLUG ASSY,SIZE 1 | |
 | TE Connectivity 206060-1 | CPC PLUG ASSEMBLY SIZE 11-4 | |
 | TE Connectivity 3-747579-0 | SHLDNG FERRULE, PLTD, BULK PKG | |
 | TE Connectivity 350536-1 | UMNL SOK 20-14 .0126 PTPBR | |
 | TE Connectivity 350715-1 | 06P UMNL PLUG HSG | |
 | TE Connectivity 350766-1 | 03P UMNL PLUG HSG | |
 | TE Connectivity 350777-1 | 02P UMNL PLUG HSG | |
 | TE Connectivity 350778-1 | 02P UMNL CAP HSG | |
 | TE Connectivity 350779-1 | 04P UMNL PLUG HSG | |
 | TE Connectivity 350780-1 | 04P UMNL CAP HSG | |
 | TE Connectivity 350781-1 | 06P UMNL CAP HSG | |
 | TE Connectivity 350782-1 | 09P UMNL CAP HSG | |
 | TE Connectivity 35432 | TERMINAL,SOLIS R 16-14HD 8 | |
 | TE Connectivity 5205208-1 | CRIMP SNAP PLUG ASSY, 25 POS | |
 | TE Connectivity 5748676-5 | DIE CAST CBL CLMP KIT,SZ 5 | |
For Use With
Product Change Notice
| Effective Date | Description of Change | Download | |||
|---|---|---|---|---|---|
| 08/30/2024 | PCN-24-218910 - Feature Change. Please be aware of an upcoming feature change to the listed part numbers. The new parts have increased corner keying support for sealing areas. | Download | |||
| 01/15/2018 | E-17-013712 - Product Improvement. Material upgrade for better supply chain. | Download | |||
| 04/01/2013 | Project Lantern PTP Migration Parts - MNF. location change from NC. | Download | |||
Availability
Immediate Shipment:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
Additional Resources
| Attribute | Value |
|---|---|
| TE Connectivity: | 350720-1 |
| Other Names: | 500-020-2570 D76178-000 403049182 AMPS-0-0350720-1 |
