1-770987-0

AMP1-770987-0
Heilind Number:AMP1-770987-0
Manufacturer:TE Connectivity
Manufacturer Number:1-770987-0
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

MINI UMNL PIN 22-18 AWG AU LP

More >>

Specifications

AttributeValue
Product Category:
Power Connectors Battery & Coin Cell Clips, Contacts & Holders
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 1-770987-0
Series:Mini-Universal MATE-N-LOK
Accessory Type:Contact
Mount Type:Cable Mount (Free-Hanging)
Termination Method:Crimp
Contact Material:Brass
Voltage:600 V AC, 600 V DC
Contact Type:Pin
Wire Type:Stranded
Cable Type:Discrete Wire
Contact Amperage:9.5 A
Termination Type:Crimp
Operating Temperature Range:-55 - 105 °C, -67 - 221 °F
Circuit Application:Power
Contact Mating Area Plating:Gold
Contact Mating Area Plating Thickness:30 µin, .76 µm
Contact Termination Plating Thickness:1.27 µm, 50 µin
Contact Underplating Material:Nickel
Connector and Contact Terminate To:Wire & Cable
Wire Size:18 - 22 AWG, .3 - .9 mm²
Connector System:Wire to Wire
Contact Termination Plating:Tin
Contact Underplating Thickness:1.27 µm, 50 µin
Wire Insulation Support:Without
Accepts Wire Insulation Diameter:.059 - .094 in, 1.5 - 2.39 mm
Contact Retention:With
Glow Wire Rating:Standard Part - Not Glow Wire
VDE Tested:No
For Multiple Crimp:No
Contact Orientation:Straight
Wire Contact Termination Area Plating Material:Tin
Crimp Area Plating Finish:Bright
Crimp Area Plating Thickness:1.27 µm, 50 µin
Contact Product Type:Contact
Mating Pin Diameter:.039 in, 1 mm
Standards Met:UL
Part Aliases:1-770987-0
SKU:AMP1-770987-0

Detailed Description

Introducing the MINI UMNL PIN 22-18 AWG AU LP, a vital component in the Mini-Universal MATE-N-LOK series. This contact features a cable mount design for convenient free-hanging installation via crimp termination, ensuring secure connectivity in power applications. Constructed with durable brass and plated with gold, it offers reliable performance with a voltage rating of 600 V AC/DC. Suitable for 18-22 AWG stranded wires, this contact is sold in a package of 1000, making it ideal for bulk installations. With a current rating of 9.5 A and operating temperature range of -55 to 105°C, it guarantees efficient operation even in harsh environments. RoHS compliant and featuring tin plating, this contact is a dependable and environmentally friendly solution for your power connector needs.
