2716-202

WAG2716-202
ICC Number:WAG2716-202
Manufacturer:WAGO
Manufacturer Number:2716-202
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

PCB terminal block; lever; 16 mm²; Pin spacing 15 mm; 2-pole; CAGE CLAMP®; gray

More >>

Specifications

AttributeValue
Product Category:
Terminal Blocks PCB Mount Terminal Blocks
Manufacturer:WAGO
Manufacturer Part Number:WAGO 2716-202
Series:2716
Housing Material:Nylon
Mount Type:Through Hole
Termination Method:Clamp
Contact Material:Electrolytic Copper
Contact Plating:Tin
Maximum Operating Temperature:60 °C
Minimum Operating Temperature:-35 °C
Pitch:15 mm
Number of Poles:2
Number of Levels:1
Housing Color:Gray
Wire Size:16 to 6 AWG
Flammability Rating:UL 94V-0
Current Rating:76 A
Voltage Rating:1000 V
Conductor Size:16 to 6 AWG
Operating Temperature:-35 to 60 °C
Mounting Type:Through Hole
Part Aliases:27160202
SKU:WAG2716-202

Detailed Description

Introducing the 2716-202 PCB Terminal Block, a high-performance connectivity solution for your electronic projects. This terminal block, part of the 2716 series, features a durable Nylon housing and Through Hole mount type for secure installation. With Cage Clamp termination method and Electrolytic Copper contacts plated with Tin, it ensures reliable and efficient connections. Operating in temperatures ranging from -35°C to 60°C, this terminal block is suitable for various environments. Its 2 poles and 1 level design, along with a 15mm pitch, offer versatility in wiring applications. Rated for 76A and 1000V, with UL 94V-0 flammability certification and RoHS compliance, it guarantees safety and quality. Compatible with 16-6 AWG wire sizes, this terminal block is ideal for high-power and industrial settings. Upgrade your connectivity with the 2716-202.
