SGD-120-3
STRING POT, 120 INCH RANGE
The SGD-120-3 is a high-performance STRING POT with a 120 inch range, making it ideal for precise linear position sensing in various applications. This sensor, featuring a durable String Potentiometer design, operates reliably in temperatures ranging from -18 to 71 °C (0 to 160 °F). With a linear range of 120 inches (3048 mm), it offers accurate and consistent measurement capabilities. The output options of 4-20 mA and 0-10 VDC ensure compatibility with a wide range of systems. This product, part of our Position Sensors and HVAC Sensors campaign, is RoHS compliant, underlining its commitment to environmental sustainability. Trust the SGD1203 for dependable and efficient rotary and linear position sensing.
| Product Category: | |
| Manufacturer: | TE Connectivity | Sensors |
| Manufacturer Part Number: | TE Connectivity | Sensors SGD-120-3 |
| Sensor Type: | String Potentiometer |
| Operating Temperature Range: | 0 - 160 °F, -18 - 71 °C |
| Linear Range: | 120 in, 3048 mm |
| Output: | 0 - 10 VDC, 4 - 20 mA |
| SKU: | TSSSGD-120-3 |
| series: | MEAS SG |
| Cable Actuated Position Sensor Housing Material: | Polycarbonate + Stainless Mounting Bracket |
| Hazardous Area Approvals: | No |
| IP Rating: | IP67 |
| Resolution: | Continuous Analog |
| Encoder Drive: | No |
| Measuring Cable: | Nylon-Coated Stainless Steel |
| Repeatability: | .02 % of FS |
| Cable Actuated Position Sensor Accuracy: | .35 % of FS |
| Supplier Product: | Cable Actuated Position Sensors |
Environmental Initiative Details
| Environmental Initiative: | RoHS |
|---|---|
| Compliant: | Unknown |
| Date of this Information: | Unknown |
| Notes: |
