189-009-513R571

TEX189_009_513R571
Heilind Number:TEX189-009-513R571
Manufacturer:NorComp
Manufacturer Number:189-009-513R571
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

Female over Female .625" Dual-Port D-Sub 9 Position Right Angle PCB Dip Solder

More >>

Specifications

AttributeValue
Product Category:
D-Sub & D-Ribbon Connectors & Accessories D-Sub Connectors
Manufacturer:NorComp
Manufacturer Part Number:NorComp 189-009-513R571
Series:189
Gender:Receptacle over Receptacle
Termination Method:Solder
Contact Plating:Gold Flash
Maximum Operating Temperature:105 °C
Minimum Operating Temperature:-55 °C
Mount Angle:Right Angle
Number of Positions:9
Shell Material:Steel
Shell Finish:Nickel Plated
Current Rating:5 A
Voltage Rating:250 VAC
SKU:TEX189-009-513R571

Detailed Description

Introducing the 189-009-513R571, a high-performance Female over Female .625" Dual-Port D-Sub Connector. This right-angle PCB dip solder connector features 9 gold flash plated contacts, ensuring reliable signal transmission in demanding applications. With a wide operating temperature range of -55°C to 105°C and a voltage rating of 250 VAC, it is suitable for use in diverse environments. The rugged steel shell with nickel plating offers excellent durability, while its compact design saves space on the PCB. RoHS compliant and rated for 5 A current, this connector is ideal for industrial and commercial projects requiring secure and efficient I/O connectivity.
