180-015-173L000

TEX180_015_173L000
Heilind Number:TEX180-015-173L000
Manufacturer:NorComp
Manufacturer Number:180-015-173L000
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

Male High-Density Crimp & Poke D-Sub 15 Position Straight Crimp and Poke

More >>

Specifications

AttributeValue
Product Category:
D-Sub & D-Ribbon Connectors & Accessories D-Sub Connectors
Manufacturer:NorComp
Manufacturer Part Number:NorComp 180-015-173L000
Gender:Plug
Series:180
Mount Angle:Straight
Shell Finish:Nickel Plated
Current Rating:3 A
Shell Material:Steel
Termination Method:Crimp
Number of Positions:15
Maximum Operating Temperature:100 °C
Minimum Operating Temperature:-50 °C
Signal Wire Size:24-26 AWG
SKU:TEX180-015-173L000

Detailed Description

Introducing the 180-015-173L000, a high-density Male Crimp & Poke D-Sub connector designed for reliable signal transmission in industrial applications. With 15 straight termination positions, this plug ensures secure connections for 24-26 AWG wires. Constructed with a durable steel shell and nickel plating, it offers excellent mechanical strength and corrosion resistance, suitable for harsh environments. Operating efficiently between -50 °C and 100 °C, this connector is perfect for a wide range of industrial settings. With a current rating of 3 A and RoHS compliance, rest assured of its performance and environmental responsibility. Upgrade your connectivity with the 180-015-173L000 for seamless data transfer in your systems.
