172-037-103R001

TEX172_037_103R001
Heilind Number:TEX172-037-103R001
Manufacturer:NorComp
Manufacturer Number:172-037-103R001
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

Male D-Sub 37 Position Straight Solder Cup

More >>

Specifications

AttributeValue
Product Category:
D-Sub & D-Ribbon Connectors & Accessories D-Sub Connectors
Manufacturer:NorComp
Manufacturer Part Number:NorComp 172-037-103R001
Series:172
Gender:Plug
Termination Method:Solder Cup
Contact Plating:Gold Flash
Maximum Operating Temperature:100 °C
Minimum Operating Temperature:-50 °C
Mount Angle:Straight
Number of Positions:37
Shell Material:Steel
Signal Wire Size:20-26 AWG
Shell Finish:Nickel Plated
Current Rating:5 A
Voltage Rating:250 VAC
SKU:TEX172-037-103R001

Detailed Description

Introducing the 172-037-103R001, a high-performance Male D-Sub 37 Position Straight Solder Cup connector from our M SERIES. This rugged plug boasts a durable steel shell with nickel-plated finish, ensuring reliable connectivity in demanding environments. Gold Flash contact plating guarantees excellent signal transmission, while accommodating 20-26 AWG signal wire sizes. With a current rating of 5 A and voltage rating of 250 VAC, this connector is suitable for a wide range of applications. Its solder cup termination method allows for secure and efficient installation, with a straight mount angle for easy integration. Operating between -50°C and 100°C, and fully RoHS compliant, the 172-037-103R001 is the perfect choice for your high-reliability connectivity needs.
