87831-1421

MOL87831-1421
Heilind Number:MOL87831-1421
Manufacturer:Molex
Manufacturer Number:87831-1421
Datasheet:Drawing
ECAD Model:
3D Model

Description:

2.00mm Pitch Milli-Grid Header, Vertical, Through Hole, Shrouded, 14 Circuits, 0.76

More >>

Specifications

AttributeValue
Product Category:
PC Board Pin & Receptacle Connectors PCB Pin Headers
Manufacturer:Molex
Manufacturer Part Number:Molex 87831-1421
Color:Black
Series:87831 - Milli-Grid
Amperage:2 A
Connector Type:Milli-Grid
Number of Contacts:14
Number of Rows:2
Termination Method:Through Hole
Contact Material:Phosphor Bronze
Body Orientation:Straight
Pitch:2 mm
Voltage:125 V
Material:Nylon
Orientation:Vertical
Keying:No
Tail Length:2.5 mm
Packaging:Tube
Operating Temperature Range:-55 - 105 °C
Contact Mating Area Plating:Gold
Contact Mating Area Plating Thickness:.762 µm
Number of Contacts Loaded:14
Mating Cycles:100
PCB Locator:No
PCB Retention:Without
Polarized to PCB:No
Contact Termination Plating Thickness:1.905 µm
PCB Thickness (Recommended):1.6 mm
Connector System:Wire to Board
CSA Agency Certification:LR19980
UL Agency Certification:E29179
Contact Termination Plating:Tin
Maximum Solder Process Temperature:260 °C
Lead Free Process Capability:WAVE
Duration at Max. Process Temperature (seconds):010
Max. Cycles at Max. Process Temperature:001
Termination Pitch:2 mm
Glow Wire Capable:No
Guide to Mating Part:No
Lock to Mating Part:Yes
Stackable:No
Surface Mount Compatible:Yes
Breakaway:No
Make First / Break Last:No
Shroud Type:Yes
Material Flammability Standard:94V-0
Part Aliases:0878311421
SKU:MOL87831-1421

Detailed Description

The 87831-1421 is a high-performance PCB pin header connector from the Milli-Grid series, featuring 14 gold-plated contacts for reliable signal transmission. With a low amperage rating of 2A and a voltage of 125V, it is suitable for various electronic applications. This straight, through-hole connector is constructed with a durable nylon body and phosphor bronze contacts, ensuring longevity and stability in operation. It is UL and CSA certified, RoHS compliant, and lead-free solder compatible, meeting industry standards for quality and environmental responsibility. Ideal for wire-to-board connections, this black connector with a 2mm pitch and vertical orientation is a dependable choice for your design needs. With a tube packaging for convenience and protection, it guarantees secure and efficient assembly in your projects.
