78443-1001
1.00mm Pitch DDR3 DIMM Socket, Low LLCR, Press Fit, Vertical, with Pegs, Black Housing and Latches, 0.76
Part Aliases: Molex 0784431001
Featuring a high-performance design, the 78443-1001 is a top-of-the-line DDR3 DIMM socket for all your memory connection needs. With a durable housing made of high temperature thermoplastic and gold-plated phosphor bronze contacts, this socket ensures reliable performance even in demanding environments. Boasting a low amperage of 1A and a voltage rating of 30V AC/DC, it guarantees safe and efficient operation. The 240 compliant pin termination method offers secure connectivity, while the black housing and tray packaging add a touch of sleekness to its overall design. With UL and CSA agency certifications, as well as RoHS compliance, you can trust in the quality and reliability of this socket for your projects. Upgrade your system with the 78443-1001 and experience seamless memory connectivity like never before.
Details
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 78443-1001 |
| Series: | 78443 - DDR3 DIMM |
| Amperage: | 1 A |
| Connector Type: | DDR3 DIMM |
| Housing Material: | High Temperature Thermoplastic |
| Number of Contacts: | 240 |
| Termination Method: | Through Hole - Compliant Pin |
| Contact Material: | Phosphor Bronze |
| Contact Plating: | Gold |
| Maximum Operating Temperature: | 85 °C |
| Pitch: | 1 mm |
| Voltage: | 30 V AC/DC |
| Material: | High Temperature Thermoplastic |
| Socket Type: | DIMM |
| Keying: | Yes |
| SDRAM Type: | DDR3 |
| Component Type: | Socket |
| Housing Color: | Black |
| Tail Length: | 3.3 mm |
| Packaging: | Tray |
| Operating Temperature Range: | -55 - 85 °C |
| Contact Mating Area Plating: | Gold |
| Contact Mating Area Plating Thickness: | .762 µm |
| Number of Contacts Loaded: | 240 |
| Mating Cycles: | 25 |
| PCB Locator: | Yes |
| PCB Retention: | Yes |
| Contact Termination Plating Thickness: | .381 µm |
| PCB Thickness (Recommended): | 3.6 mm |
| CSA Agency Certification: | LR19980 |
| UL Agency Certification: | E29179 |
| Contact Termination Plating: | Tin |
| Termination Pitch: | 1 mm |
| Electrical Model: | Yes |
| Voltage Key: | Center |
| Material Flammability Standard: | 94V-0 |
| Part Aliases: | 0784431001 |
| SKU: | MOL78443-1001 |
Frequently bought together
Compliance
Environmental Initiative Details
| Environmental Initiative: | RoHS |
|---|---|
| Compliant: | Unknown |
| Date of this Information: | Unknown |
| Notes: |
Product Change Notice
Product Change Notice
| Effective Date | Description of Change | Download |
|---|---|---|
| 10/31/2025 | 515981 - Obsolete no replacement. LTB 6/25/25 LTS 9/25/25 | Download |
| 01/15/2016 | GCM 10743605 - Change In Packaging Specifications. This letter is to inform you that Molex is changing from HDPE Bag to moisture barrier bag (MBB) for selected connectors from 78443 series, DDR3 connector. MBB Bag will have better moisture barrier properties as compared to HDPE bag, and is better able to keep moisture out Part Numbers affected are: 784431001 784431002 784430107 There is no changes to the connector specification, SPQ/MOQ or carton size. | Download |
| 07/31/2015 | GCM 10699704 - Tooling / Equipment Transfer. | Download |
| 08/21/2014 | GCM 10626670 - Tooling / Equipment Transfer. | Download |
| 08/21/2014 | GCM 10626671 - Tooling / Equipment Transfer. | Download |
