| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 53254-0270 |
| Series: | 53254 - Micro-Latch |
| Amperage: | 2 A |
| Connector Type: | Micro-Latch |
| Number of Contacts: | 2 |
| Number of Rows: | 1 |
| Termination Method: | Through Hole |
| Contact Material: | Brass |
| Body Orientation: | Right Angle |
| Pitch: | 2 mm |
| Voltage: | 125 V |
| Material: | Nylon |
| Orientation: | Right Angle |
| Tail Length: | 3.5 mm |
| Operating Temperature Range: | -40 - 105 °C |
| Contact Mating Area Plating: | Tin |
| Contact Mating Area Plating Thickness: | 1.016 µm |
| Number of Contacts Loaded: | 2 |
| Mating Cycles: | 30 |
| PCB Locator: | No |
| PCB Retention: | Yes |
| Polarized to PCB: | No |
| Contact Termination Plating Thickness: | 1.016 µm |
| Polarized to Mate: | Yes |
| PCB Thickness (Recommended): | 1.6 mm |
| Connector System: | Wire to Board |
| Contact Termination Plating: | Tin |
| Glow Wire Capable: | No |
| Lock to Mating Part: | Yes |
| Stackable: | No |
| Surface Mount Compatible: | No |
| Breakaway: | No |
| Make First / Break Last: | No |
| Shroud Type: | Partial |
| Part Aliases: | 0532540270 |
| SKU: | MOL53254-0270 |
53254-0270
Specifications
Detailed Description
Introducing the 53254-0270 Micro-Latch Connector, a reliable and high-performance solution for your PCB connection needs. With a low amperage rating of 2A and featuring two brass contacts, this right-angle connector ensures efficient power and signal transmission in tight spaces. Constructed with durable nylon and tin-plated contact mating areas, it offers excellent conductivity and longevity, even in harsh environments. Its through-hole termination method and PCB retention capability guarantee secure installation, while its compact 2mm pitch and 30 mating cycles make it ideal for space-constrained applications. RoHS compliant and with a wide operating temperature range, this connector is suitable for various industries, from consumer electronics to automotive. Upgrade your connectivity with the 53254-0270 Micro-Latch Connector.
