52207-0860
Easy-On FFC/FPC Connector, 1.00mm Pitch, Slider Series, Right-Angle, Top Contact, 2.70mm Height, 8 Circuits, Gold Plating
Part Aliases: Molex 0522070860
The 52207-0860, a high-performance Easy-On FFC/FPC Connector designed for seamless connectivity in electronic applications. With a slim 1.00mm pitch, this Slider Series connector features a convenient right-angle, top contact design, perfect for space-constrained PCB layouts. Boasting 8 circuits and reliable gold plating, it ensures efficient signal transmission with a low amperage of 1A and a maximum voltage of 125V. Constructed from durable nylon housing and featuring phosphor bronze contacts, it offers excellent durability and conductivity. Operating flawlessly in temperatures ranging from -30 to 85°C, this connector is RoHS compliant, making it a reliable and environmentally friendly choice for your projects. Trust the 52207-0860 for secure and high-speed FFC/FPC connections in your electronic designs.
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 52207-0860 |
| Color: | Natural |
| Series: | 52207 |
| Amperage: | 1 A |
| Connector Type: | Easy-On |
| Housing Material: | Nylon |
| Number of Rows: | 1 |
| Contact Material: | Phosphor Bronze |
| Contact Plating: | Gold |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -30 °C |
| Body Orientation: | Right Angle |
| Pitch: | 1 mm |
| Voltage: | 125 V |
| Material: | Nylon |
| Orientation: | Right Angle |
| Wire Type: | FFC/FPC |
| Actuator Type: | Slider |
| Tail Length: | 2 mm |
| Operating Temperature Range: | -30 - 85 °C |
| Contact Mating Area Plating: | Gold |
| Number of Contacts Loaded: | 8 |
| Mating Cycles: | 30 |
| PCB Locator: | No |
| PCB Retention: | Yes |
| Polarized to PCB: | Yes |
| Contact Termination Plating: | Tin |
| Termination Pitch: | 1 mm |
| Mated Height: | 2.7 mm |
| Stackable: | No |
| PCB Mount Alignment Type: | Surface Mount |
| Product Name: | Easy-On |
| Material Flammability Standard: | 94V-0 |
| Part Aliases: | 0522070860 |
| SKU: | MOL52207-0860 |
Environmental Initiative Details
| Environmental Initiative: | RoHS |
|---|---|
| Compliant: | Unknown |
| Date of this Information: | Unknown |
| Notes: |
Product Change Notice
| Effective Date | Description of Change | Download |
|---|---|---|
| 10/01/2023 | 513555 - Equipment Transfer, Production Transfer or Rearrangement. This notification is to inform about 52207 series production order from Molex Shizuoka & Molex Malaysia will be consolidated to Molex Malaysia. No changes will be made to product as part of this change. | Download |
