50098-8000

MOL50098-8000
Heilind Number:MOL50098-8000
Manufacturer:Molex
Manufacturer Number:50098-8000
Datasheet:Drawing
ECAD Model:
3D Model

Description:

4.00mm Pitch Board-In Crimp Terminal 50098, 18-22 AWG, Reel, for 51036 Housing

More >>

Specifications

AttributeValue
Product Category:
Pin & Socket Housings & Contacts Pin & Socket Contacts
Manufacturer:Molex
Manufacturer Part Number:Molex 50098-8000
Series:50098 - Board-in
Connector Type:Board-in
Gender:Male
Termination Method:Crimp or Compression
Contact Material:Phosphor Bronze
Contact Plating:Tin
Circuit Application:Signal
Contact Mating Area Plating:Tin
Contact Mating Area Plating Thickness:.889 µm
Contact Termination Plating Thickness:.914 µm
Wire Size:18 AWG, 20 AWG, 22 AWG
Connector System:Wire to Board
Contact Termination Plating:Tin
Wire Insulation Diameter:1.8 - 2.6 mm
Part Aliases:0500988000
SKU:MOL50098-8000

Detailed Description

Introducing the 50098-8000, a high-performance male Board-in connector designed for seamless signal transmission in electronic circuits. This versatile connector features a durable phosphor bronze contact material with tin plating, ensuring reliable conductivity. With options for crimp or compression termination methods, it accommodates 22 AWG to 18 AWG wire sizes, making it ideal for a wide range of applications. The tin-plated contact termination and mating areas provide added corrosion resistance, while the reel packaging offers convenience for bulk installations. RoHS compliant and in stock for immediate shipping, the 50098-8000 is the perfect choice for your wire to board connector needs.
