44485-1212
Mini-Fit Jr. Plus Crimp Terminal, 18-24 AWG, Bag, Phosphor Bronze, Select Gold (Au)
Part Aliases: Molex 0444851212
The Mini-Fit Jr. Plus Crimp Terminal, a reliable solution for your power connectivity needs. Designed for 18-24 AWG wires, this female connector features Phosphor Bronze construction with Select Gold (Au) plating for enhanced durability and conductivity. With a current rating of 13 A, it ensures efficient power transmission in various applications. The tin-lead contact termination and gold-plated mating area guarantee secure and stable connections. Packaged in a convenient bag, this terminal is suitable for crimp or compression installation methods. In compliance with RoHS standards, it is also environmentally friendly. Upgrade your power systems with the Mini-Fit Jr. Plus Crimp Terminal for dependable performance.
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 44485-1212 |
| Series: | 44485 - Mini-Fit Jr. |
| Amperage: | 13 A |
| Connector Type: | Mini-Fit Jr. |
| Gender: | Female |
| Termination Method: | Crimp or Compression |
| Contact Material: | Phosphor Bronze |
| Contact Plating: | Tin Lead |
| Packaging: | Bag |
| Circuit Application: | Power |
| Contact Mating Area Plating: | Gold |
| Contact Mating Area Plating Thickness: | .762 µm |
| Wire Size: | 18 AWG, 20 AWG, 22 AWG, 24 AWG |
| Contact Termination Plating: | Tin-Lead |
| Wire Insulation Diameter: | 1.3 - 3.1 mm |
| Product Name: | Mini-Fit Jr. |
| Part Aliases: | 0444851212 |
| SKU: | MOL44485-1212 |
Environmental Initiative Details
| Environmental Initiative: | RoHS |
|---|---|
| Compliant: | Unknown |
| Date of this Information: | Unknown |
| Notes: |
