| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 39-00-0084 |
| Series: | 5558 - Mini-Fit |
| Amperage: | 9 A |
| Connector Type: | Mini-Fit |
| Gender: | Male |
| Termination Method: | Crimp or Compression |
| Contact Material: | Phosphor Bronze |
| Contact Plating: | Tin |
| Voltage: | 600 V |
| Circuit Application: | Power |
| Contact Mating Area Plating: | Tin |
| Contact Mating Area Plating Thickness: | 3.048 µm, .914 µm |
| Mating Cycles: | 30 |
| Contact Termination Plating Thickness: | 3.048 µm, .914 µm |
| Wire Size: | 16 AWG |
| Connector System: | Wire to Wire |
| Contact Termination Plating: | Tin |
| Wire Insulation Diameter: | 1.8 - 3.1 mm |
| Part Aliases: | 0039000084 5558PBT3L |
| SKU: | MOL39-00-0084 |
39-00-0084
| Heilind Number: | MOL39-00-0084 |
| Manufacturer: | Molex |
| Manufacturer Number: | 39-00-0084 |
| Datasheet: | RoHS Certificate of Compliance |
| ECAD Model: | |
Specifications
Detailed Description
Introducing the Molex Mini-Fit Male Crimp Terminal, a reliable solution for your power connectivity needs. This terminal, part number 39-00-0084, is constructed from durable Tin (Sn) over Phosphor Bronze, suitable for 16 AWG wires. With a current rating of 9 A and a voltage tolerance of 600 V, it ensures efficient power transmission in various applications. Featuring a tin-plated contact mating area and a crimp or compression termination method, this terminal guarantees secure and low-resistance connections. Compliant with RoHS standards, it is also environmentally friendly. Upgrade your wire-to-wire or wire-to-board connections with this high-quality Mini-Fit terminal.
