| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 38969-0002 |
| Series: | 38969 - TSE |
| Amperage: | 50 A |
| Connector Type: | TSE |
| Number of Contacts: | 2 |
| Number of Rows: | 1 |
| Maximum Operating Temperature: | 120 °C |
| Minimum Operating Temperature: | -40 °C |
| Body Orientation: | Straight |
| Pitch: | 12.7 mm |
| Voltage: | 600 V |
| Orientation: | Vertical |
| Component Type: | One Piece |
| Tail Length: | 4 mm |
| Operating Temperature Range: | -40 - 120 °C |
| Number of Contacts Loaded: | 2 |
| PCB Retention: | Without |
| Polarized to Mate: | Yes |
| PCB Thickness (Recommended): | 1.57 mm |
| Wire Size: | 10 AWG, 12 AWG, 14 AWG, 16 AWG, 18 AWG, 20 AWG, 8 AWG |
| Termination Pitch: | 12.7 mm |
| Lock to Mating Part: | No |
| Stackable: | No |
| Surface Mount Compatible: | No |
| Part Aliases: | 0389690002 |
| SKU: | MOL38969-0002 |
38969-0002
| Heilind Number: | MOL38969-0002 |
| Manufacturer: | Molex |
| Manufacturer Number: | 38969-0002 |
| Datasheet: | RoHS Certificate of Compliance |
| ECAD Model: | |
Description:
12.70mm Pitch, Single Row Tri-Barrier Terminal Strip, without Mounting Ends, 2 Circuits
More >>Specifications
Detailed Description
The 38969-0002 is a high-performance barrier terminal block designed for robust power connections in industrial applications. Featuring a TSE connector type with 2 contacts in a single row, this terminal block offers secure and efficient wire termination. With a wide operating temperature range from -40°C to 120°C, it is suitable for use in harsh environments. The straight body orientation and vertical mounting option allow for easy integration into your system. Certified for UL standards and RoHS compliant, this terminal block ensures safety and environmental responsibility. Its 600V voltage rating and 50A amperage make it ideal for power-intensive setups. The 38969-0002 is a reliable solution for your connectivity needs, with stock availability for immediate shipping.
Frequently Bought Together
| Product | Part # | Description | Stock |
|---|---|---|---|
 | Molex 02-09-1102 | 2.36mm Diameter, Standard .093 Pin and Socket Crimp Terminal, Series 1189, Female, with Tin (Sn) Plated Brass Contact, 14-20 AWG, Reel |  |
 | Molex 02-09-2101 | 2.36mm Diameter, Standard .093 Pin and Socket Crimp Terminal, Series 1190, Male, with Tin (Sn) Plated Brass Contact, 14-20 AWG, Reel | |
 | Molex 03-09-1011 | 2.36mm Diameter Standard .093 Pin and Socket Receptacle Housing, 1 Circuit, Friction Lock, Natural | |
 | Molex 03-09-1022 | 2.36mm Diameter Standard .093 Pin and Socket Receptacle Housing, 2 Circuits, without Mounting Ears, with Ramps, Natural | |
 | Molex 03-09-2022 | 2.36mm Diameter Standard .093 Pin and Socket Plug Housing, 2 Circuits, without Mounting Ears, Natural | |
 | Molex 19160-0012 | Closed-End Insulated Splice for 14-22 AWG Wire, Clear | |
 | Molex 19705-4201 | PCB Tab Quick Disconnect, Male, for Wire, Box, Tab 6.35 x 0.81mm | |
 | Molex 22-15-2126 | KK 254 PC Board Connector, Right-Angle, End-to-End Stackable, 2.54?m Tin (Sn), 12 Circuits | |
