| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 34830-2001 |
| Color: | Black |
| Series: | 34830 - MX150 |
| Connector Type: | MX150 |
| Number of Contacts: | 20 |
| Number of Rows: | 2 |
| Termination Method: | Through Hole - Compliant Pin |
| Contact Material: | Copper Alloy |
| Body Orientation: | Right Angle |
| Pitch: | 3.5 mm |
| Voltage: | 250 V |
| Material: | PBT |
| Orientation: | Right Angle |
| Keying: | No |
| Operating Temperature Range: | -40 - 125 °C |
| Contact Mating Area Plating: | Tin |
| Number of Contacts Loaded: | 20 |
| Mating Cycles: | 10 |
| PCB Thickness (Recommended): | 1.6 mm |
| Connector System: | Wire to Board |
| Contact Termination Plating: | Tin |
| Maximum Solder Process Temperature: | 260 °C |
| Lead Free Process Capability: | WAVE |
| Duration at Max. Process Temperature (seconds): | 025 |
| Max. Cycles at Max. Process Temperature: | 001 |
| Glow Wire Capable: | No |
| Guide to Mating Part: | No |
| Breakaway: | No |
| Make First / Break Last: | No |
| Part Aliases: | 0348302001 |
| SKU: | MOL34830-2001 |
34830-2001
| Heilind Number: | MOL34830-2001 |
| Manufacturer: | Molex |
| Manufacturer Number: | 34830-2001 |
| Datasheet: | Application Specification |
| ECAD Model: | |
Description:
MX150 2x10 Dual Row Right Angle Header, 20 Circuits, Polarization A, Black, Solder Tail
More >>Specifications
Detailed Description
Introducing the MX150 2x10 Dual Row Right Angle Header, a high-performance connector designed for PCB applications. With 20 circuits and polarization A, this black header features solder tail termination for secure and reliable connections. Constructed with a durable PBT body and tin contact plating, it offers excellent conductivity and longevity, even in harsh environments. Operating temperature range from -40 to 125 °C and voltage rating of 250 V ensure versatility and safety. Perfect for wire-to-board connections, this RoHS-compliant header is lead-free wave solder compatible, with a maximum solder process temperature of 260 °C. With its compact 3.5 mm pitch and right-angle orientation, it's ideal for space-constrained designs. Trust the MX150 for high-reliability applications in automotive, industrial, and consumer electronics.
