| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 34824-2204 |
| Color: | Black |
| Series: | 34824 - Mini50 |
| Connector Type: | Mini50 |
| Gender: | Receptacle |
| Number of Contacts: | 20 |
| Number of Rows: | 2 |
| Pitch: | 2 mm |
| Material: | Nylon |
| Keying: | Yes |
| Polarization: | A |
| Operating Temperature Range: | -40 - 105 °C |
| Circuit Application: | Power |
| Polarized to Mate: | Yes |
| Connector System: | Wire to Board |
| Termination Pitch: | 2 mm |
| Glow Wire Capable: | No |
| Lock to Mating Part: | Yes |
| Stackable: | No |
| Part Aliases: | 0348242204 |
| SKU: | MOL34824-2204 |
34824-2204
| ICC Number: | MOL34824-2204 |
| Manufacturer: | Molex |
| Manufacturer Number: | 34824-2204 |
| Datasheet: | Datasheet |
| ECAD Model: | |
Description:
PROPOSED REPLACEMENT: MINI50 GEN II UNSEALED RECEPTACLES (206523 SERIES); Mini50 Unsealed Receptacle, Dual Row, Bridged, with CPA, 20 Circuits, EcoPaXX Resin, Polarization Option A, Black
More >>Specifications
Detailed Description
Introducing the 34824-2204, a high-quality Mini50 Unsealed Receptacle designed for optimal performance. This dual-row, bridged connector features a CPA for added security, housing 20 circuits. Constructed with durable EcoPaxx Resin in sleek black, it offers reliable power connectivity. With Polarization Option A, it ensures proper alignment during installation. Suitable for wire-to-board applications, this connector boasts a 2mm pitch and is rated for operating temperatures ranging from -40 to 105°C. RoHS compliant and featuring keying for added safety, the Mini50 is a versatile and dependable solution for your connectivity needs.
