| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 33472-1301 |
| Color: | Black, Natural |
| Series: | 33472 - MX150 |
| Connector Type: | MX150 |
| Gender: | Receptacle |
| Number of Contacts: | 12 |
| Number of Rows: | 2 |
| Pitch: | 3.5 mm |
| Material: | Modified Polystyrene Alloy |
| Keying: | Yes |
| Polarization: | A |
| Operating Temperature Range: | -40 - 125 °C |
| Circuit Application: | Power |
| Polarized to Mate: | Yes |
| Connector System: | Wire to Board, Wire to Wire |
| Glow Wire Capable: | No |
| Lock to Mating Part: | Yes |
| Stackable: | No |
| Part Aliases: | 0334721301 |
| SKU: | MOL33472-1301 |
33472-1301
| Heilind Number: | MOL33472-1301 |
| Manufacturer: | Molex |
| Manufacturer Number: | 33472-1301 |
| Datasheet: | Product Specification |
| ECAD Model: | |
Description:
MX150 Sealed Female Connector, Dual Row, 12 Circuits, Polarization A, without Connector Position Assurance, with Clip-Slot, Black
More >>Specifications
Detailed Description
Introducing the MX150 Sealed Female Connector, a high-performance solution for power circuit applications. With 12 circuits arranged in a dual row configuration, this connector ensures reliable connectivity in demanding environments. Featuring Polarization A and a clip-slot for secure mating, it guarantees proper alignment and retention. Constructed from a durable Modified Polystyrene Alloy, it offers excellent performance in a wide operating temperature range from -40 to 125 °C. RoHS compliant and designed for wire to wire or wire to board connections, the MX150 is a versatile and reliable choice for your connectivity needs.
