| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 22-55-2401 |
| Color: | Black |
| Series: | 70450 |
| Connector Type: | SL |
| Gender: | Receptacle |
| Housing Material: | Polyester |
| Number of Contacts: | 40 |
| Number of Rows: | 2 |
| Pitch: | 2.54 mm |
| Material: | Polyester |
| Operating Temperature Range: | -40 - 105 °C |
| Circuit Application: | Signal |
| Connector System: | Wire to Board |
| Glow Wire Capable: | No |
| Stackable: | Yes |
| Breakaway: | No |
| Product Name: | SL |
| Material Flammability Standard: | 94V-0 |
| Part Aliases: | 0022552401 70450-0019 |
| SKU: | MOL22-55-2401 |
22-55-2401
| Heilind Number: | MOL22-55-2401 |
| Manufacturer: | Molex |
| Manufacturer Number: | 22-55-2401 |
| Datasheet: | RoHS Certificate of Compliance |
| ECAD Model: | |
Description:
2.54mm Pitch SL Crimp Housing, Dual Row, Version A, Non-polarized, 40 Circuits, Black
More >>Specifications
Detailed Description
With the Molex SL Connector, you can easily and securely make wire-to-board connections for your electronic devices. This black, 2-row receptacle features a durable polyester housing and is designed for signal applications. With 40 contacts and a pitch of 2.54mm, it offers reliable connectivity. Operating in temperatures ranging from -40 to 105°C, this connector is suitable for a variety of environments. RoHS compliant and stackable, it provides added convenience for your assembly needs. Perfect for use in a wide range of electronic applications, the SL Connector ( 22-55-2401) is a dependable and versatile choice.
