| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 19099-0048 |
| Color: | Yellow |
| Series: | 19099 - InsulKrimp |
| Connector Type: | InsulKrimp |
| Contact Plating: | Tin |
| Stud Size: | 8 (M4) |
| Insulation Material: | PVC |
| Packaging: | Bag |
| Contact Mating Area Plating: | Tin |
| Wire Size: | 10 AWG, 12 AWG, 3.3 - 5 mm² |
| CSA Agency Certification: | LR18689 |
| UL Agency Certification: | E32244 |
| Wire Insulation Diameter: | 6.4 mm |
| Barrel Type: | Closed |
| Material Flammability Standard: | 94V-0 |
| Part Aliases: | 0190990048 C-2718-08X |
| SKU: | MOL19099-0048 |
19099-0048
| Heilind Number: | MOL19099-0048 |
| Manufacturer: | Molex |
| Manufacturer Number: | 19099-0048 |
| Datasheet: | Product Specification |
| ECAD Model: | |
Specifications
Detailed Description
Designed for secure and efficient wire connections, the 19099-0048 InsulKrimp Snap Spade Terminal is a must-have for electrical projects. With a vibrant yellow color for easy identification, this terminal is suitable for 10-12 AWG wires. Featuring a durable PVC insulation and tin contact plating, it ensures reliable performance. Certified by LR18689 and E32244, it meets stringent quality standards. The closed barrel design provides added protection, accommodating wire insulation up to 6.4mm in diameter. RoHS compliant and in stock for immediate shipping, this terminal is essential for professionals and DIY enthusiasts alike.
