| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 19071-0223 |
| Color: | Natural |
| Series: | 19071 - InsulKrimp |
| Connector Type: | InsulKrimp |
| Contact Plating: | Tin |
| Stud Size: | 10 (M5) |
| Insulation Material: | PVC |
| Contact Mating Area Plating: | Tin |
| Wire Size: | 10.5 - 16.8 mm², 6 AWG |
| Wire Insulation Diameter: | 11.18 mm |
| Barrel Type: | Closed |
| Material Flammability Standard: | 94V-0 |
| Part Aliases: | 0190710223 E-660-10XT |
| SKU: | MOL19071-0223 |
19071-0223
Specifications
Detailed Description
Introducing the 19071-0223 InsulKrimp Brazed Ring Tongue Terminal, designed for secure and efficient wire connections. This terminal is suitable for 6 AWG wires, with an expanded flare for easy installation. Featuring a stud size of 10 (M5) and a length of 40.54mm, it offers versatility in connectivity. The terminal is constructed with durable PVC insulation and tin contact plating, ensuring reliable performance. With a wire size range of 10.5 - 16.8 mm² and a closed barrel design, it provides a tight and secure fit. RoHS compliant and featuring a Mylar Tape Carrier, this terminal is ideal for various industrial applications. Trust in the quality and efficiency of the 19071-0223 for your wire termination needs.
Frequently Bought Together
| Product | Part # | Description | Stock |
|---|---|---|---|
 | Molex 15-97-9061 | Mini-Fit TPA Key for 6 Circuit |  |
 | Molex 172709-0004 | Mini-Fit TPA2, Terminal Position Assurance (TPA) Retainer, 4.20mm Pitch, UL 94V-0, Low-Halogen, 4 Circuits, White | |
 | Molex 19071-0145 | InsulKrimp Ring Tongue Terminal for 8 AWG Wire, Stud Size 5/16 (M8), Length 3.17mm, Mylar Tape Carrier | |
 | Molex 19071-0181 | InsulKrimp Ring Tongue Terminal for 8 AWG Wire, Stud Size 10 (M5), Mylar Tape Carrier | |
 | Molex 19071-0192 | InsulKrimp Brazed Ring Tongue Terminal for 6 AWG Wire, Expanded Flare, Stud Size 1/4 (M6), Length 42.34mm, Mylar Tape Carrier | |
 | Molex 19071-0198 | InsulKrimp Brazed Ring Tongue Terminal for 6 AWG Wire, Expanded Flare, Stud Size 5/16 (M8), Length 42.34mm, Mylar Tape Carrier | |
 | Molex 19071-0225 | InsulKrimp Ring Tongue Terminal for 6 AWG Wire | |
 | Molex 19071-0250 | InsulKrimp Ring Tongue Terminal for 4 AWG Wire | |
 | Molex 19161-0333 | Splash Proof Snap Plug Insulator | |
 | Molex 33472-2006 | MX150 Sealed Female Connector, Dual Row, 20 Circuits, Polarization A, with Connector Position Assurance, Black | |
 | Molex 33482-4001 | MX150 Sealed Male Connector, Dual Row, 4 Circuits, Polarization A, without Connector Position Assurance, Black | |
 | Molex 36664-0001 | MLX Crimp Terminal 42024, 10-12 AWG, Reel, Tin (Sn) | |
Product Change Notice
| Effective Date | Description of Change | Download | |||
|---|---|---|---|---|---|
| 03/04/2019 | 506690 - Supplier Change. This letter is to inform you that Molex is adding a new supplier or the supplier is making a change affecting the part(s) identified in this notice. There will be no negative impact to product performance as a result of this change. | Download | |||
| 02/18/2019 | 506408 - Packaging Method/Quantity Changing. This letter is to inform you that the part(s) referenced in this notice will undergo packaging specification changes that may include new container sizes, quantities or changes to the label. No changes will be made to the product as a result of this change. | Download | |||
Availability
Immediate Shipment:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
Additional Resources
| Attribute | Value |
|---|---|
| Molex: | 19071-0223 |
| Other Names: | 0190710223 E-660-10XT |
