| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 173112-0224 |
| Specification Type: | High Density |
| Series: | 173112 |
| Amperage: | 5 A |
| Gender: | Male |
| Contact Material: | Brass |
| Contact Plating: | Gold Over Nickel |
| Contact Type: | Machined Crimp Contact |
| Operating Temperature Range: | -55 - 130 °C |
| Contact Mating Area Plating: | Gold over Nickel |
| Contact Mating Area Plating Thickness: | .8 µm |
| Type: | High Density |
| Contact Termination Plating Thickness: | .8 µm |
| Wire Size: | 24 AWG, 26 AWG, 28 AWG |
| Product Name: | FCT Products |
| Part Aliases: | 1731120224 FK22P-08V-5783 |
| SKU: | MOL173112-0224 |
173112-0224
Specifications
Detailed Description
Introducing the HPD High-Density Machined Crimp Contact, a crucial component for your connectivity needs. This male contact, featuring a 0.80 specification, is designed for high-density applications, making it ideal for space-constrained environments. With a current rating of 5 A, it ensures reliable power transmission. Constructed from brass with gold over nickel plating, this contact offers excellent conductivity and corrosion resistance, even in harsh operating conditions ranging from -55 to 130 °C. The gold over nickel mating area plating, 0.8 µm thick, guarantees durable and low-resistance connections. Suitable for 24-28 AWG wires, this RoHS-compliant contact is perfect for your power connector projects. Trust in FCT Products for high-quality connectivity solutions. Available for immediate shipping.
Frequently Bought Together
| Product | Part # | Description | Stock |
|---|---|---|---|
 | Molex 105300-1200 | Cut Strip - Nano-Fit Crimp Terminal, Female, 0.38 |  |
 | Molex 105308-1204 | Nano-Fit Receptacle Housing, TPA Capable, 2.50mm Pitch, Dual Row, 4 Circuits, Black, Glow-Wire Capable | |
 | Molex 172704-0096 | FCT Metal Backshell for D-Sub Connector, Shell Size 1, Straight Cable Outlet, Large Inner Chamber, with Rubber Bushing and #4-40 Locking Screws | |
 | Molex 172704-0143 | FCT High Power Contact, Male, Straight, Crimp, 0.8µm Gold Mating Plating, 0.2µm Gold Termination Plating, 20A, 14-12 AWG | |
 | Molex 172708-0006 | Mini-Fit TPA2 Receptacle Housing, 4.20mm Pitch, Dual Row, UL 94V-0, Low-Halogen, 6 Circuits | |
 | Molex 173112-0227 | HPD High-Density Machined Crimp Contact, Female, 0.80 | |
 | Molex 173113-0021 | FCT High-Density D-Sub Crimp Housing, Male, 44 Circuits | |
 | Molex 173113-0071 | FCT High-Density D-Sub Crimp Housing, Male, 26 Circuits | |
 | Molex 173113-0075 | FCT High-Density D-Sub Crimp Housing, Female, 44 Circuits | |
 | Molex 39-00-0038 | Mini-Fit Female Crimp Terminal, Tin (Sn) over Copper (Cu) Plated Brass, Double 22+22 or Single 24-18 AWG, Reel | |
 | Molex 43020-0801 | Micro-Fit 3.0 Plug Housing, Dual Row, 8 Circuits, UL 94V-0, Low-Halogen, Black | |
 | Molex 43030-0006 | Micro-Fit 3.0 Crimp Terminal, Female, with Select Gold (Au) Plated Phosphor Bronze Contact, 30-26 AWG, Reel | |
Product Change Notice
| Effective Date | Description of Change | Download | |||
|---|---|---|---|---|---|
| 06/17/2021 | Packaging Method/Quantity Changing. Part(s) referenced in this notice will undergo packaging specification changes that may include a new Delivery unit, packaging size, changes to the label or packaging material. No changes will be made to the product as a result of this change. | Download | |||
Availability
Immediate Shipment:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
Additional Resources
| Attribute | Value |
|---|---|
| Molex: | 173112-0224 |
| Other Names: | 1731120224 FK22P-08V-5783 |
