173107-0365
FCT Mixed Layout D-Sub Connector, Female, Straight, Solder Cup, Gold Plating, Tin-plated Shell without Dimples, 5 Circuits, 4 Signal Contacts Loaded
Part Aliases: Molex 1731070365 Molex FM5W1S-K121
The FCT Mixed Layout D-Sub Connector, a high-performance solution for your connectivity needs. This female connector features a straight orientation and solder cup termination method, with gold plating for optimal signal transmission. With five circuits, including four loaded signal contacts, it offers reliable connectivity in a variety of applications. The green color and tin-plated shell without dimples provide both visual appeal and durability, while its 7.5 A amperage rating ensures robust power delivery. Constructed with copper alloy contacts and a PBT insert material, this connector is designed to withstand harsh operating environments, with an operating temperature range of -55 to 130 °C. RoHS compliant and with a mating cycle of 500, it guarantees long-lasting performance in industrial and commercial settings. Upgrade to the FCT Mixed Layout D-Sub Connector for seamless and secure connectivity.
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 173107-0365 |
| Color: | Green |
| Series: | 173107 |
| Amperage: | 7.5 A |
| Gender: | Female |
| Number of Contacts: | 5 |
| Number of Rows: | 2 |
| Termination Method: | Solder Cup |
| Contact Material: | Copper Alloy |
| Contact Plating: | Gold Over Nickel |
| Pitch: | 2.84 mm |
| IP Rating: | IP20 |
| Shell Plating: | Tin |
| Number of Ports: | 1 |
| Orientation: | Straight |
| Insert Material: | PBT |
| Shell Material: | Steel |
| Operating Temperature Range: | -55 - 130 °C |
| Contact Mating Area Plating Thickness: | .8 µm |
| Number of Contacts Loaded: | 4 |
| Mating Cycles: | 500 |
| Panel Mount: | Rear |
| Panel Mount Method: | Flange |
| PCB Locator: | No |
| Shielded: | Yes |
| PCB Retention: | Without |
| Type: | Mixed Layout |
| Mating Pitch: | 2.84 mm |
| Polarized to Mate: | Yes |
| Wire Size: | 20 AWG |
| Waterproof Dustproof: | No |
| Product Name: | FCT Products |
| Part Aliases: | 1731070365 FM5W1S-K121 |
| SKU: | MOL173107-0365 |
Environmental Initiative Details
| Environmental Initiative: | RoHS |
|---|---|
| Compliant: | Unknown |
| Date of this Information: | Unknown |
| Notes: |
