| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 172708-1002 |
| Housing Material: | Nylon |
| Number of Rows: | 2 |
| Pitch: | 4.2 mm |
| Polarization: | Yes |
| Number of Positions: | 2 |
| Housing Color: | Black |
| Connector and Housing Type: | Receptacle |
| Flammability Rating: | UL 94V-0 |
| Operating Temperature: | -40 to 105 °C |
| SKU: | MOL172708-1002 |
172708-1002
Specifications
Detailed Description
Introducing the Mini-Fit Sigma Receptacle Housing, a versatile and durable connector for your power applications. With a compact 4.20mm pitch and featuring dual rows, this housing is designed for efficient wire-to-wire or wire-to-board connections. Constructed from high-quality black nylon, it is not only RoHS compliant but also glow-wire capable for added safety. The 2-circuit design offers convenience and flexibility, with each contact polarized for secure mating. Engineered for reliability, it includes a locking feature to ensure a stable connection. Compatible with Mini-Fit Jr. Plug Housings and Mini-Fit TPA2 Plug Housings, as well as Mini-Fit Jr. Headers, this housing is a perfect choice for various applications. Trust in the Molex Wire-to-Wire/Wire-to-Board mcampaign for all your connectivity needs.
Frequently Bought Together
| Product | Part # | Description | Stock |
|---|---|---|---|
 | Molex 172718-4121 | Mini-Fit TPA2/Sigma Female Crimp Terminal, Brass, Pre-Plated Tin (Sn), Double 22+22 or Single 20-18 AWG, 2.10-2.85mm Insulation Diameter |  |
 | Molex 43031-0001 | Micro-Fit 3.0 Crimp Terminal, Male, with Tin (Sn) Plated Phosphor Bronze Contact, 24-20 AWG, Reel | |
Product Change Notice
| Effective Date | Description of Change | Download | |||
|---|---|---|---|---|---|
| 04/08/2027 | 518681 - Equipment Transfer. PSBU is transferring all Hetero molding ( molds & presses) from Lincoln 3104 to Nogales 3105 over the next 18 months. There are approximately 450 molds and 18 presses to transfer. To facilitate this, a series of PCNs will be issued covering group of molds (approx 25-30 molds per group) which use the same resin. | Download | |||
| 11/24/2025 | 516765 - Capacity change or tool replacement. Molex Lincoln Nebraska is adding capacity tooling that will impact the products referenced in the attached list. There will be no changes in fit, form, function or appearance of product based on this additional capacity tooling. | Download | |||
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
