| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 172704-0042 |
| Color: | Black |
| Series: | 172704 |
| Gender: | Female |
| Number of Contacts: | 2 |
| Number of Rows: | 1 |
| IP Rating: | IP20 |
| Shell Plating: | Tin |
| Number of Ports: | 1 |
| Insert Material: | PBT |
| Shell Material: | Steel |
| Operating Temperature Range: | -55 - 130 °C |
| Panel Mount: | Rear |
| Panel Mount Method: | Flange |
| PCB Locator: | No |
| Shielded: | Yes |
| PCB Retention: | Without |
| Type: | Mixed Layout |
| Polarized to Mate: | Yes |
| Waterproof Dustproof: | No |
| Product Name: | FCT Products |
| Part Aliases: | 1727040042 F2W2SC-K121 |
| SKU: | MOL172704-0042 |
172704-0042
Specifications
Detailed Description
Introducing the FCT Mixed Layout D-Sub Housing, a high-quality connectivity solution for your electronic devices. This female housing features a durable black PBT insert with a tin-plated steel shell, offering excellent protection and longevity. With 2 circuits and a polarized design, it ensures secure and reliable connections. The rear panel mount with flange method makes installation easy, while its IP20 rating provides some protection against dust and moisture. RoHS compliant and suitable for a wide range of applications, the FCT Mixed Layout D-Sub Housing is a dependable choice for your connectivity needs.
