| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 15134-1001 |
| Color: | Natural |
| Series: | 15134 - PicoBlade OTS |
| Amperage: | 1 A |
| Connector Type: | PicoBlade OTS |
| Gender: | Female |
| Termination Method: | Crimp or Compression |
| Contact Material: | Phosphor Bronze |
| Voltage: | 125 V |
| Material: | Polyester |
| Wire Type: | UL 1061 |
| Cable Length: | 100 mm |
| Contact Mating Area Plating: | Tin |
| Contact Mating Area Plating Thickness: | .889 µm |
| Number of Contacts Loaded: | 10 |
| Mating Pitch: | 1.25 mm |
| Contact Termination Plating Thickness: | .914 µm |
| Wire Size: | 28 AWG |
| Contact Termination Plating: | Tin |
| Wire Insulation Diameter: | .9 mm |
| Lock to Mating Part: | Yes |
| Connector Assembly Type: | Dual Ended Connectors |
| Connector To Connector: | PicoBlade to PicoBlade |
| Part Aliases: | 0151341001 |
| SKU: | MOL15134-1001 |
15134-1001
Specifications
Detailed Description
The PicoBlade Female-to-Female Off-the-Shelf Cable Assembly ( 15134-1001) offers a convenient solution for connecting devices with its 100.00mm length and 10 circuits. Constructed with durable natural-colored polyester and UL 1061 wire, this assembly ensures reliable performance. Featuring female PicoBlade OTS connectors with crimp or compression termination, it accommodates 28 AWG wires. With a voltage rating of 125V and 1A amperage, it is suitable for various applications. Each contact is made of tin-plated phosphor bronze for enhanced conductivity. This RoHS-compliant assembly is in stock and ready for immediate shipping, making it an ideal choice for your connectivity needs.
Product Change Notice
| Effective Date | Description of Change | Download | |||
|---|---|---|---|---|---|
| 06/09/2023 | 513527 - Equipment Transfer, Production Transfer or rearrangement. 51021 series product will be transferred from Japan vendor to Ansan plant in Korea for the productivity improvement & stable delivery performance. | Download | |||
| 01/31/2023 | 512731 - Change Supplier. Current vendor flame retardant issues lead to delayed delivery and not enough capacity to support orders. Need add alternative source to ensure orders delivery on time. No changes will be made to product as part of this change. | Download | |||
| 08/05/2022 | 510507 - Packaging method/qty change. After packing with MXK specification, there is still space in the box and packing loss is occurring. By changing the MXK packaging specifications, we can pack more products in the free space in the box than we do now. | Download | |||
| 09/30/2021 | 510820 - Change Supplier. The purpose of this letter is to change the resin material from SABIC's resin to LG Chemical's resin in order to overcome the current resin shortage issue of Molex Korea. Implementation is only for Korean Products only. | Download | |||
| 09/19/2019 | 507718 - Packaging Method/Quantity Changing. This letter is to inform you that the part(s) referenced in this notice will undergo packaging specification changes that may include new container sizes, quantities or changes to the label. No changes will be made to the product as a result of this change. | Download | |||
Availability
Immediate Shipment:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
Additional Resources
| Attribute | Value |
|---|---|
| Molex: | 15134-1001 |
| Other Names: | 0151341001 |
