| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 15-06-0146 |
| Color: | Natural |
| Series: | 42475 - Mini-Fit BMI |
| Amperage: | 13 A |
| Connector Type: | Mini-Fit BMI |
| Gender: | Plug |
| Housing Material: | Nylon |
| Number of Contacts: | 14 |
| Number of Rows: | 2 |
| Mount Type: | Panel Mount |
| Pitch: | 4.2 mm |
| Material: | Nylon |
| Operating Temperature Range: | -40 - 105 °C |
| Circuit Application: | Power |
| Polarized to Mate: | Yes |
| Connector System: | Wire to Board, Wire to Wire |
| Termination Pitch: | 4.2 mm |
| Glow Wire Capable: | No |
| Lock to Mating Part: | Yes |
| Stackable: | No |
| Material Flammability Standard: | 94V-0 |
| Part Aliases: | 0015060146 42475-1421 |
| SKU: | MOL15-06-0146 |
15-06-0146
| Heilind Number: | MOL15-06-0146 |
| Manufacturer: | Molex |
| Manufacturer Number: | 15-06-0146 |
| Datasheet: | 3D Drawing |
| ECAD Model: | |
Description:
Mini-Fit BMI Plug Housing, 4.20mm Pitch Dual Row with Panel Mount Ears, PA Polyamide Nylon 6/6, UL 94V-0, 14 Circuits
More >>Specifications
Detailed Description
Introducing the Molex Mini-Fit BMI Plug Housing, a reliable solution for your power circuit applications. This housing, featuring a 4.20mm pitch dual row design with panel mount ears, is constructed from durable PA Polyamide Nylon 6/6 material, ensuring both strength and safety with a UL 94V-0 rating. With 14 circuits accommodated, it allows for efficient power transmission. The natural color and polarized mating feature add convenience to installation. Suitable for wire-to-wire or wire-to-board connectors, this housing is RoHS compliant and operates effectively in a wide temperature range from -40 to 105 °C. Trust in the Molex Mini-Fit BMI Plug Housing for secure and high-performance power connectivity in your electronic systems.
