| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 105313-1303 |
| Color: | Black |
| Series: | 105313 |
| Amperage: | 6.5 A |
| Connector Type: | Nano-Fit |
| Number of Contacts: | 3 |
| Number of Rows: | 1 |
| Termination Method: | Through Hole |
| Contact Material: | Brass |
| Body Orientation: | Right Angle |
| Pitch: | 2.5 mm |
| Voltage: | 300 V |
| Material: | Liquid Crystal Polymer |
| Orientation: | Right Angle |
| Keying: | Yes |
| Tail Length: | 3.2 mm |
| Operating Temperature Range: | -40 - 115 °C |
| Contact Mating Area Plating: | Gold over Nickel |
| Contact Mating Area Plating Thickness: | .762 µm |
| Number of Contacts Loaded: | 3 |
| Mating Cycles: | 50 |
| PCB Locator: | Yes |
| PCB Retention: | Yes |
| Polarized to PCB: | Yes |
| Contact Termination Plating Thickness: | 1.524 µm |
| Polarized to Mate: | Yes |
| PCB Thickness (Recommended): | 1.6 mm, 2.4 mm |
| Connector System: | Wire to Board |
| Contact Termination Plating: | Tin over Nickel |
| Termination Pitch: | 2.5 mm |
| Glow Wire Capable: | Yes |
| Guide to Mating Part: | No |
| Lock to Mating Part: | Yes |
| Stackable: | No |
| Surface Mount Compatible: | No |
| Breakaway: | No |
| Shroud Type: | Yes |
| Product Name: | Nano-Fit |
| Material Flammability Standard: | 94V-0 |
| Part Aliases: | 1053131303 |
| SKU: | MOL105313-1303 |
105313-1303
Specifications
Detailed Description
Introducing the Nano-Fit Right Angle Header, a high-performance through-hole connector designed for seamless power and signal transmission in compact electronic applications. With a narrow 2.50mm pitch and featuring a single row of 3 circuits, this black header ensures efficient board space utilization. Constructed with durable liquid crystal polymer material and brass contacts, it guarantees reliable operation in demanding environments. Boasting a maximum amperage of 6.5 A and a voltage rating of 300 V, the Nano-Fit is ideal for power-intensive systems. Its right-angle body orientation and PCB locator offer easy and secure installation, while gold over nickel contact plating ensures low contact resistance. With a wide operating temperature range of -40 to 115 °C and ROHS compliance, this connector is suitable for various industrial applications. Trust in the Nano-Fit for high-quality, high-reliability connectivity in your projects.
