105311-1102
Nano-Fit Vertical Header, Through Hole, 2.50mm Pitch, Single Row, 2 Circuits, with Solder Clips, Tin (Sn) Plating, Black
Part Aliases: Molex 1053111102
The Nano-Fit Vertical Header, a compact and efficient solution for your power connector needs. This single-row header features 2 circuits, each capable of carrying up to 6.5 A of current at 250 V AC/DC. With a pitch of 2.5 mm and through-hole termination, it offers secure and reliable connectivity on your PCB. The brass contacts are plated with tin over nickel for enhanced durability, even in high-temperature environments. Designed for easy assembly, this header is polarized both to the PCB and mating connector, with PCB retention for added security. RoHS compliant and glow wire capable, it meets stringent safety standards. Trust the Nano-Fit Vertical Header for seamless power transmission in your electronic applications.
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 105311-1102 |
| Color: | Black |
| Series: | 105311 |
| Amperage: | 6.5 A |
| Connector Type: | Nano-Fit |
| Number of Contacts: | 2 |
| Number of Rows: | 1 |
| Termination Method: | Through Hole |
| Contact Material: | Brass |
| Body Orientation: | Straight |
| Pitch: | 2.5 mm |
| Voltage: | 250 V AC/DC |
| Material: | Liquid Crystal Polymer |
| Orientation: | Vertical |
| Keying: | Yes |
| Tail Length: | 3.2 mm |
| Operating Temperature Range: | -40 - 105 °C |
| Contact Mating Area Plating: | Tin over Nickel |
| Contact Mating Area Plating Thickness: | 1.524 µm |
| Number of Contacts Loaded: | 2 |
| Mating Cycles: | 25 |
| PCB Locator: | Yes |
| PCB Retention: | Yes |
| Polarized to PCB: | Yes |
| Contact Termination Plating Thickness: | 1.524 µm |
| Polarized to Mate: | Yes |
| PCB Thickness (Recommended): | 1.6 mm, 2.4 mm |
| Connector System: | Wire to Board |
| Contact Termination Plating: | Tin over Nickel |
| Termination Pitch: | 2.5 mm |
| Glow Wire Capable: | Yes |
| Guide to Mating Part: | No |
| Lock to Mating Part: | Yes |
| Stackable: | No |
| Surface Mount Compatible: | No |
| Breakaway: | No |
| Shroud Type: | Yes |
| Product Name: | Nano-Fit |
| Material Flammability Standard: | 94V-0 |
| Part Aliases: | 1053111102 |
| SKU: | MOL105311-1102 |
