10-89-7502
2.54mm Pitch C-Grid Breakaway Header, Dual Row, Vertical, High Temperature, 50 Circuits, 0.38
Part Aliases: Molex 0010897502 Molex A-70280-0065
The 10-89-7502 C-Grid PCB Connector, a high-performance solution for your board-to-board and wire-to-board connection needs. This black connector, part of the 70280 series, features 50 gold-plated contacts for reliable signal transmission. With a low amperage rating of 3 A and a voltage tolerance of 250 V, it's perfect for various electronic applications. The straight, through-hole design with a 2.54 mm pitch and 2.79 mm tail length ensures easy and secure installation. Made of high-temperature thermoplastic, it can withstand operating temperatures ranging from -40 to 105 °C. RoHS-compliant and lead-free process capable, this connector guarantees both performance and environmental responsibility. Whether you need a single connector or a bulk order, contact us for availability. Enhance your connectivity with the 10-89-7502 C-Grid PCB Connector.
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 10-89-7502 |
| Color: | Black |
| Series: | 70280 - C-Grid |
| Amperage: | 3 A |
| Connector Type: | C-Grid |
| Number of Contacts: | 50 |
| Number of Rows: | 2 |
| Termination Method: | Through Hole |
| Contact Material: | Copper Alloy |
| Body Orientation: | Straight |
| Pitch: | 2.54 mm |
| Voltage: | 250 V |
| Material: | High Temperature Thermoplastic |
| Orientation: | Vertical |
| Keying: | No |
| Tail Length: | 2.79 mm |
| Operating Temperature Range: | -40 - 105 °C |
| Contact Mating Area Plating: | Gold |
| Contact Mating Area Plating Thickness: | .381 µm |
| Number of Contacts Loaded: | 50 |
| Mating Cycles: | 50 |
| PCB Locator: | No |
| PCB Retention: | Without |
| Polarized to PCB: | No |
| Contact Termination Plating Thickness: | 2.032 µm |
| Polarized to Mate: | No |
| PCB Thickness (Recommended): | 1.6 mm |
| Connector System: | Board to Board, Wire to Board |
| Contact Termination Plating: | Tin |
| Maximum Solder Process Temperature: | 260 °C |
| Lead Free Process Capability: | SMC and Wave |
| Glow Wire Capable: | No |
| Guide to Mating Part: | No |
| Lock to Mating Part: | No |
| Stackable: | Yes |
| Breakaway: | Yes |
| Make First / Break Last: | No |
| Shroud Type: | No |
| Material Flammability Standard: | 94V-0 |
| Part Aliases: | 0010897502 A-70280-0065 |
| SKU: | MOL10-89-7502 |
Environmental Initiative Details
| Environmental Initiative: | RoHS |
|---|---|
| Compliant: | Unknown |
| Date of this Information: | Unknown |
| Notes: |
