10-84-4022

MOL10-84-4022
Heilind Number:MOL10-84-4022
Manufacturer:Molex
Manufacturer Number:10-84-4022
Datasheet:Packaging Specifications
ECAD Model:
3D Model

Description:

6.35mm Pitch MLX Power Connector, 2.13mm Contact Diameter, Vertical, PA Polyamide (Nylon) 6/6, Tin (Sn), White, 2 Circuits

More >>

Specifications

AttributeValue
Product Category:
PC Board Pin & Receptacle Connectors PCB Pin Headers
Manufacturer:Molex
Manufacturer Part Number:Molex 10-84-4022
Color:Natural
Series:42002 - MLX
Amperage:13.5 A, 20 A
Connector Type:MLX
Number of Contacts:2
Number of Rows:1
Termination Method:Through Hole
Contact Material:Phosphor Bronze
Body Orientation:Straight
Pitch:6.35 mm
Voltage:600 V
Material:Nylon
Orientation:Vertical
Tail Length:4.3 mm
Packaging:Carton
Operating Temperature Range:-55 - 105 °C
Contact Mating Area Plating:Tin
Number of Contacts Loaded:2
Mating Cycles:50
PCB Retention:Without
Polarized to PCB:Yes
PCB Thickness (Recommended):.9 mm
Connector System:Wire to Board
CSA Agency Certification:LR19980
UL Agency Certification:E29179
Contact Termination Plating:Tin
Maximum Solder Process Temperature:260 °C
Lead Free Process Capability:WAVE
Duration at Max. Process Temperature (seconds):010
Glow Wire Capable:No
Lock to Mating Part:Yes
Surface Mount Compatible:No
Breakaway:No
Material Flammability Standard:94V-2
Part Aliases:0010844022 A-42002-2A2A1
SKU:MOL10-84-4022

Detailed Description

Introducing the 10-84-4022, a high-performance MLX connector designed for seamless wire-to-board connections. With a low amperage rating of 20 A and 13.5 A, this connector is perfect for delicate electronic applications. Featuring two contacts in a single row configuration, it ensures a secure and reliable connection. The phosphor bronze contact material with tin plating guarantees excellent conductivity and corrosion resistance. Its straight body orientation and vertical mounting option make it versatile for various PCB layouts. Rated for up to 600 V, this connector is suitable for power and signal transmission. With UL and CSA certifications, you can trust in its quality and safety. RoHS compliant and lead-free solder capable, it meets environmental standards. Whether for industrial or consumer electronics, the 10-84-4022 is the ideal choice for your connectivity needs.
