08-50-0032

MOL08-50-0032
Heilind Number:MOL08-50-0032
Manufacturer:Molex
Manufacturer Number:08-50-0032
Datasheet:Drawing
ECAD Model:
3D Model

Description:

KK 254 Cat Ear Crimp Terminal 4809, 22-30 AWG, Hot Tin Dip, Bag

More >>

Specifications

AttributeValue
Product Category:
Pin & Socket Housings & Contacts Pin & Socket Contacts
Manufacturer:Molex
Manufacturer Part Number:Molex 08-50-0032
Series:4809 - Cat Ear - KK 254
Connector Type:Cat Ear, KK 254
Gender:Female
Termination Method:Crimp or Compression
Contact Material:Brass
Contact Plating:Tin
Circuit Application:Signal
Contact Mating Area Plating:Tin
Contact Mating Area Plating Thickness:1.016 µm
Contact Termination Plating Thickness:1.016 µm
Wire Size:22 AWG, 24 AWG, 26 AWG, 28 AWG, 30 AWG
Connector System:Wire to Board
Contact Termination Plating:Tin
Wire Insulation Diameter:1.57 mm
Part Aliases:0008500032 4809C-(P918)L
SKU:MOL08-50-0032

Detailed Description

Introducing the 08-50-0032 KK 254 Cat Ear Crimp Terminal 4809, a high-quality female connector designed for optimal signal transmission in wire to board applications. This versatile terminal, compatible with 22-30 AWG wires, features a durable brass construction with a tin plating for enhanced conductivity and corrosion resistance. The Hot Tin Dip termination method ensures secure and reliable connections, while the compact Cat Ear design allows for easy installation in tight spaces. Packaged in a convenient bag, this terminal is RoHS compliant and suitable for a wide range of industrial and commercial uses. Upgrade your connectivity with the 08-50-0032 KK 254 Cat Ear Crimp Terminal 4809.
