| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Molex |
| Manufacturer Part Number: | Molex 03-09-2049 |
| Color: | Natural |
| Series: | 2163 |
| Amperage: | 11 A |
| Connector Type: | Standard .093" |
| Gender: | Plug |
| Housing Material: | Nylon |
| Number of Contacts: | 4 |
| Number of Rows: | 2 |
| Pitch: | 5.03 mm |
| Material: | Nylon |
| Packaging: | Bag |
| Operating Temperature Range: | -40 - 105 °C |
| Circuit Application: | Power |
| Polarized to Mate: | Yes |
| Connector System: | Wire to Wire |
| CSA Agency Certification: | LR19980 |
| UL Agency Certification: | E29179 |
| Termination Pitch: | 5.03 mm |
| Glow Wire Capable: | No |
| Lock to Mating Part: | Yes |
| Stackable: | No |
| Product Name: | Standard .093" |
| Material Flammability Standard: | 94V-2 |
| Part Aliases: | 0003092049 2163-P1 |
| Contact Detail: | 2x2 |
| SKU: | MOL03-09-2049 |
03-09-2049
| Heilind Number: | MOL03-09-2049 |
| Manufacturer: | Molex |
| Manufacturer Number: | 03-09-2049 |
| Datasheet: | RoHS Certificate of Compliance |
| ECAD Model: | |
Description:
2.36mm Diameter Standard .093 Pin and Socket Plug Housing, 4 Circuits, Dual Row, without Mounting Ears, Natural
More >>Specifications
Detailed Description
The Standard .093" connector system is a reliable and versatile solution for power applications, featuring a nylon housing and four contacts in a 2-row configuration. With a current rating of 11A and UL and CSA certifications, this connector ensures safety and performance. Operating in a wide temperature range from -40 to 105°C, it is suitable for various environments. Its polarized plug design and locking mechanism guarantee secure connections. RoHS compliant and with glow wire capability, this connector meets international standards for safety and environmental responsibility. Perfect for wire-to-wire connections, it is a essential component for any project.
