09185406904

HRT09185406904
Heilind Number:HRT09185406904
Manufacturer:HARTING
Manufacturer Number:09185406904
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

SEK, Standard, Connector; Male connector; Thermoplastic resin (PBT), Beige; PCB to cable; Wave soldering termination; Rated current: 1A; Contacts: 40

More >>

Specifications

AttributeValue
Product Category:
PC Board Pin & Receptacle Connectors PCB Pin Headers
Manufacturer:HARTING
Manufacturer Part Number:HARTING 09185406904
Color:Gray
Series:SEK Standard
Housing Material:Plastic
Number of Contacts:40
Number of Rows:2
Termination Method:Solder
Contact Material:Copper Alloy
Contact Plating:Noble Metal Over Nickel, Tin Over Nickel
Maximum Operating Temperature:125 °C
Minimum Operating Temperature:-55 °C
Pitch:2.54 mm
IP Rating:IP20
Mount Angle:Straight
Tail Length:2.9 mm
Flammability Rating:UL 94V-0
Current Rating:1 A
Voltage Rating:1 kV
SKU:HRT09185406904

Detailed Description

The SEK Standard Connector is a reliable and versatile solution for your PCB to cable connections. Featuring a male connector with 40 contacts in a 2-row configuration, this connector is made of durable thermoplastic resin (PBT) in a sleek beige color. With wave soldering termination, installation is efficient and secure. Each contact is constructed of copper alloy with a tin over nickel plating, ensuring excellent conductivity and longevity. Rated for 1A and 1kV, this connector is suitable for a wide range of applications. Its straight mount angle and 2.54mm pitch offer easy integration into your designs. With UL 94V-0 flammability rating and IP20 protection, it guarantees safety and reliability. RoHS compliant and high-quality construction make this connector a perfect choice for your projects.
