| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Hirose |
| Manufacturer Part Number: | Hirose ZE05-16DS-HU/R |
| Color: | Black |
| Series: | ZE05 |
| Gender: | Male |
| Housing Material: | Nylon |
| Number of Contacts: | 16 |
| Mount Type: | Through Hole |
| Termination Method: | Crimp |
| Maximum Operating Temperature: | 125 °C |
| Minimum Operating Temperature: | -40 °C |
| Pitch: | 2 mm |
| Mount Angle: | Straight |
| Mating Cycles: | 30 cycle |
| Wire Size: | 22 - 20 AWG |
| Current Rating: | 2 A |
| Voltage Rating: | 60 V |
| SKU: | HIRZE05-16DS-HU/R |
ZE05-16DS-HU/R
| ICC Number: | HIRZE05-16DS-HU/R |
| Manufacturer: | Hirose |
| Manufacturer Number: | ZE05-16DS-HU/R |
| Datasheet: | 3D Model (IGES) |
| ECAD Model: | |
Specifications
Detailed Description
Introducing the ZE05-16DS-HU/R, a high-performance 16-position male plug designed for automotive applications. This black connector, part of the ZE05 series, features a durable nylon housing that can withstand operating temperatures ranging from -40°C to 125°C. With a through-hole mount type and crimp termination method, it offers secure and reliable connections. Rated for 2A current and 60V voltage, this connector accommodates wire sizes ranging from 22 to 20 AWG. Its straight mount angle and 2mm pitch make it suitable for various electronic systems. With RoHS compliance and 30 mating cycles, the ZE05-16DS-HU/R ensures both performance and environmental responsibility in automotive connectivity.
