HR10A-7P-4PC(73)
110-0501-1-73 EACH
The HR10A-7P-4PC(73), a high-performance male circular connector designed for rugged environments. With a durable metal housing and silver contact plating, this connector ensures reliable conductivity in demanding conditions. Featuring 4 contacts and a straight panel mount, it offers secure and easy installation. Rated for temperatures ranging from -25°C to 85°C and boasting a 1000-cycle mating life, this connector is built to last. Suitable for wire sizes 30-26 AWG, it has a current rating of 2A and a voltage rating of 150VAC. With RoHS compliance and nickel shell finish, it meets stringent environmental standards. The HR10A-7P-4PC(73) is the ideal choice for industrial and commercial applications requiring robust and dependable connectivity.
| Product Category: | |
| Manufacturer: | Hirose |
| Manufacturer Part Number: | Hirose HR10A-7P-4PC(73) |
| Series: | HR10 |
| Gender: | Male |
| Housing Material: | Metal |
| Number of Contacts: | 4 |
| Mount Type: | Panel Mount |
| Termination Method: | Crimp |
| Contact Plating: | Silver |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -25 °C |
| Shell Size: | 7 |
| Mating Type: | Push-Pull |
| Mount Angle: | Straight |
| Shell Size - Insert Arrangement: | 7-4 |
| Mating Cycles: | 1000 cycle |
| Wire Size: | 30 - 26 AWG |
| Shell Finish: | Nickel |
| Current Rating: | 2 A |
| Voltage Rating: | 150 VAC |
| SKU: | HIRHR10A-7P-4PC(73) |
Environmental Initiative Details
| Environmental Initiative: | RoHS |
|---|---|
| Compliant: | Unknown |
| Date of this Information: | Unknown |
| Notes: |
Product Change Notice
| Effective Date | Description of Change | Download |
|---|---|---|
| 02/11/2022 | HIR-430-021018 - UL Clarification. Recently, Toray Industries, Inc.,(Hereinafter Toray) announced that certain resin products were improperly identified by Toray as receiving certification from Underwriters Laboratories (hereinafter, "UL"). | Download |
