FH12-10S-0.5SVA(54)

HIRFH12-10S-0.5SVA(54).P
ICC Number:HIRFH12-10S-0.5SVA(54).P
Manufacturer:Hirose
Manufacturer Number:FH12-10S-0.5SVA(54)
ECAD Model:
3D Model

Description:

CUT TAPE - 586-0806-0-54 0.5MM FPC/FFC 10 POS CONN

More >>

Specifications

AttributeValue
Product Category:
FFC, FPC, Ribbon & IDT Connectors FFC & FPC Connectors
Manufacturer:Hirose
Manufacturer Part Number:Hirose FH12-10S-0.5SVA(54)
Pitch:0.5 mm
Gender:Female
Mount Type:Surface Mount
Mount Angle:Straight
Housing Color:Beige, Dark Brown
Current Rating:0.5 A
Number of Rows:1
Voltage Rating:50 V
Contact Plating:Gold
Contact Material:Phosphor Bronze
Housing Material:Nylon
Number of Contacts:10
Contact Orientation:Vertical
Flammability Rating:UL 94V-0
Maximum Operating Temperature:85 °C
Minimum Operating Temperature:-40 °C
Series:FH12
SKU:HIRFH12-10S-0.5SVA(54).P

Detailed Description

The FH12-10S-0.5SVA(54) is a high-performance 10-position female FPC/FFC connector, designed for cutting-edge electronic applications. Featuring a rugged nylon housing in a straight surface mount configuration, this connector ensures reliable and secure connectivity in harsh environments. With gold-plated phosphor bronze contacts, it offers excellent conductivity and signal integrity, even in high-speed data transmission systems. Rated for a wide operating temperature range from -40°C to 85°C, and with a voltage rating of 50V, this connector is suitable for diverse industrial and commercial settings. Its compact 0.5mm pitch and vertical contact orientation make it ideal for space-constrained applications, while its UL 94V-0 flammability rating guarantees safety and compliance with industry standards. RoHS compliant and currently in stock, the FH12-10S-0.5SVA(54) is the perfect choice for demanding connectivity requirements.
