| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | EDAC |
| Manufacturer Part Number: | EDAC 346-056-500-202 |
| Color: | Green |
| Amperage: | 3 A |
| Gender: | Female |
| Number of Contacts: | 56 |
| Number of Rows: | 2 |
| Termination Method: | Wire Hole |
| Contact Material: | Copper Alloy |
| Contact Plating: | Gold, Nickel, Tin |
| Pitch: | 0.125 in |
| Insulation Material: | Diallyl Phthalate |
| Row Spacing: | .2 in |
| Number of Positions: | 56 |
| Mount Orientation: | Straight |
| Operating Temperature Range: | -40 - 105 °C |
| Current Rating: | 3 A |
| Voltage Rating: | 1500 VAC |
| Card Thickness: | 0.062 in |
| Operating Temperature: | -40 to 105 °C |
| Mounting Type: | Through Hole |
| SKU: | EDA346-056-500-202 |
346-056-500-202
| ICC Number: | EDA346-056-500-202 |
| Manufacturer: | EDAC |
| Manufacturer Number: | 346-056-500-202 |
| ECAD Model: | |
Specifications
Detailed Description
Introducing our high-performance Card Edge Connectors, designed for seamless board-to-board connectivity in electronic applications. With a sleek green housing constructed from UL 94V-0 Thermoplastic Polyester, these connectors offer durability and reliability in any environment. Featuring two rows of 56 copper alloy contacts, each rated for 3A, they ensure efficient power and signal transmission. The .125-inch pitch and .2-inch row spacing allow for easy installation, while the straight mount orientation accommodates various PCB layouts. Operating flawlessly in temperatures ranging from -40 to 105°C, these RoHS-compliant connectors are suitable for a wide range of industries. Trust in the quality and performance of our Card Edge Connectors for your next project.
