| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | EDAC |
| Manufacturer Part Number: | EDAC 337-042-524-201 |
| Gender: | Female |
| Number of Contacts: | 42 |
| Number of Rows: | 2 |
| Termination Method: | Solder |
| Contact Material: | Copper Alloy |
| Contact Plating: | Gold, Nickel, Tin |
| Pitch: | 0.156 in |
| Insulation Material: | Thermoplastic Polyester |
| Current Rating: | 3 A |
| Voltage Rating: | 1800 VAC |
| Card Thickness: | 0.062 in |
| Operating Temperature: | -40 to 105 °C |
| SKU: | EDA337-042-524-201 |
337-042-524-201
Specifications
Detailed Description
Introducing our 337-042-524-201 Card Edge Connector, a reliable and high-performance solution for your PCB connectivity needs. This two-row connector features 42 positions, allowing for seamless board-to-board connections. Crafted with a durable UL 94V-0 Thermoplastic Polyester housing and copper alloy contacts, it ensures longevity and signal integrity, even in harsh environments. With a low pitch of .156 inches and .2-inch row spacing, it offers efficient signal transmission. Rated for 3A and operating temperatures ranging from -40 to 105°C, this connector is suitable for a wide range of applications. Whether you're designing consumer electronics or industrial equipment, our Card Edge Connector guarantees secure and dependable connectivity. Upgrade your PCB designs with this essential component for optimal performance.
